User Manual for Ken-A-Vision Video Flex 5400HD Fume Hood Camera Click to enlarge the picture
Contents of the user manual for the Ken-A-Vision Video Flex 5400HD Fume Hood
- Product category: Video Presenters & Document Cameras Ken-A-Vision
- Brand: Ken-A-Vision
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Ken-A-Vision Video Presenters & Document Cameras
 |
User manual for the Ken-A-Vision Video Flex 5400HD Fume Hood contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Ken-A-Vision product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Ken-A-Vision user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Ken-A-Vision product will considerably shorten its lifespan!
|
Product description The Video Flex 5400HD Fume Hood Camera from Ken-A-Vision is specifically designed with the Labconco Basic 47 Fume Hood in mind. This easy-to-use flexible neck camera can be attached to, or removed from, the fume hood with ease. You can simply attach the Video Flex Fume Hood Camera utilizing the pre-drilled hole on the Labconco Basic 47 Fume Hood. The camera can then be connected by external leads to a television monitor or multimedia projector; or simultaneously to a computer (USB connection) and then to a multimedia projector for multiple people to monitor activities inside the hood from a distance. When using a computer, Applied Vision software can be used to capture and record experiments as single images, time-lapse sequences, time-lapse movies or continuous movies. Using this camera, the experiments can be recorded over a period of hours, days or weeks, limited only by the storage capacity of your computer. - Control Features
-
- 16x digital zoom
- Manual focus
- Control White Balance automatically or manually
- Black and white mode
- Control Gamma Adjustment automatically or manually
- Supports 360° image rotation in both directions controlled by software buttons
- Capture and freeze image
- Synchronized audio recording
- Supports annotation
1 Please Note: Controlling done via software close - Software Features
-
- Applied Vision 4 and EduCam software included
- JPEG format for image compression
- Split screen through the software
- Supports 2 to 8 cameras simultaneously
- Time lapse recording for both image and video playback
- Multiple pallet tools for drawing
- Through varied programs for video playback
- Single click hardware button for document orientation
- 16:9 and/or 4:3 format auto or manual select by software
- UVC compliant single-click software button for distance learning
- Drop down to MS Word or EXCEL
- Supports vector graphics (.svg extension)
- Desktop enabled icon and single click software button via software for full screen
- Compatible with Windows XP SP2 (and later) and Mac 10.6.8 (and later)
In the Box Ken-A-Vision Video Flex 5400HD Fume Hood Camera Black Box with Four Hook-and-loop Strip Attached 6' Video Flex USB Cable 12' Video Composite Cable 120 VAC Power Supply Applied Vision Software CD Ken-A-Vision Capture the Macintosh Solution Information Limited 5-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Ken-A-Vision Video Flex 5400HD Fume Hood Camera in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersKen-A-Vision 5400HD Specs | | | Sensor | CMOS | | Sensor Resolution | 5 MP | | Frame Rate | 1920 x 1080 @ 30 fps | | Effective Pixels | 2595 x 1924 | | Output Resolution | 1920 x 1080 | | | | Capture Area | 9.25 x 7.5" / 23.4 x 19 cm | | I/O Connections | 1 x USB 2.0 | | I/O Connections | 1 x USB 2.0 | | Minimum Illumination | 8 lux | | | | Focal Length | 6 mm to Infinity | | | | Supported Microscope Eyepieces | 1.1" / 28 mm, 1.35" / 34.5 mm | | Operating System Support | Android, ChromeOS, Windows, iOS, macOS/OS X | | | | DC Input Power | 5 VDC at 0.2 A | | | | Operating Temperature | 14 to 113°F / -10 to 45°C | | | | Certifications | CE, CSA, RoHS, WEEE, as per Manufacturer | | Cable Length | 5.6' / 1.7 m | | Gooseneck Length | 25" / 63.5 cm | | Weight | 10 lb / 4.5 kg |
