User Manual for Kino Flo Image 87 DMX Yoke Mount 1-Light Kit

• Product category: Fluorescent Lights Kino Flo
• Brand: Kino Flo
• Description and content of package
• Technical information and basic settings
• Frequently asked questions – FAQ
• Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
• Authorized service for Kino Flo Fluorescent Lights

Product description

• Image 87 DMX Yoke Mount Fixture The Kino Flo Image 87 DMX Yoke Mount Fixture is a 4' wide, 8 lamp fixture with low power draw that's ideal for motion picture and TV studios. The metal alloy fixture features local and DMX dimming and lamp switching that combine for optimal flexibility in light level adjustment. A High Output switch further expands that capability with a 1/2 stop power boost. Popular for blue/green screen applications thanks to its broad, even output, the Image 87 DMX makes use of True Match 420nm blue and 525nm green lamps as well as high CRI 5500K, 3200K and 2900K fluorescents. The light's low draw combined with relatively low heat offer substantial savings in powering the fixtures and cooling the studio. This yoke mount version of the Image 87 has a 2 position yoke for varying ceiling heights and manual control of pan and tilt adjustments. An optional 1 1/8" pin is available for Junior receivers. The Image 87 DMX ships with a silver louver to narrow the beam angle, filter frame and 4 card holders to attach flags to the unit.
  Features
  • Metal alloy fixture includes gel frame, louver and cardholders
  • Broad, even light - ideal for blue and green screen
  • Instant-on, dead quiet
  • Low amperage draw equals energy savings
  • Long lamp life, low lamp replacements, low maintenance labor
  • Low operating temperature yields low air-conditioning costs
  • More efficient heat management design for stable color temperature
  • Uses 5500K, 3200K and 2900K, 420nm blue and 525nm green lamps
  • Mix lamps for various color temperatures
  • High color rendering True Match lamps work well alongside conventional quartz lights or HMIs
  • DMX control for stable color temperature and light level control
  • DMX lamp switching, HO/Standard switching
  • Instant-on, dead quiet
  • Color Gels do not burn out or fade due to lower heat of fixture
  Photometrics
  • fc
    930 fc @ 2.0' (0.6 m)
    325 fc @ 4.0' (1.2 m)
    160 fc @ 6.0' (1.8 m)
    94 fc @ 8.0' (2.4 m)
    61 fc @ 10' (3.0 m)
    44 fc @ 12' (3.6 m)
    33 fc @ 14' (4.3 m)
    26 fc @ 16' (4.9 m)
    20 fc @ 18' (5.5 m)
    17 fc @ 20' (6.0 m)
    lux
    12,490 lux @ 1.6' (0.5 m)
    4,748 lux @ 3.3' (1.0 m)
    2,412 lux @ 4.9' (1.5 m)
    1,433 lux @ 6.5' (2.0 m)
    958 lux @ 8.0' (2.5 m)
    678 lux @ 10' (3.0 m)
    505 lux @ 11.5' (3.5 m)
    394 lux @ 13' (4.0 m)
    320 lux @ 15' (4.5 m)
    265 lux @ 16.4' (5.0 m)
    f/stop fc
    930 fc @ 2.0' (0.6 m), f5.6/8
    325 fc @ 4.0' (1.2 m), f4.0/4
    160 fc @ 6.0' (1.8 m), f2.8/3
    94 fc @ 8.0' (2.4 m), f2.0/6
    61 fc @ 10' (3.0 m), f2.0
    f/stop lux
    12,490 lux @ 1.6' (0.5 m), f8.0/2
    4,748 lux @ 3.3' (1.0 m), f4.0/8
    2,412 lux @ 4.9' (1.5 m), f2.8/8
    1,443 lux @ 6.5' (2.0 m), f2.8/1
    958 lux @ 8.0' (2.5 m), f2.0/5
• Junior Pin Assembly for 80, 40, 20 Kino Flo Image 80/40/20 Junior Pin assembly. Allows straight-ahead mounting of the fixture to a Junior 1-1/8" female receptor. Includes metric threaded screws and a Junior (1-1/8") pin.
• Image 80 Ship Case (1) The Kino Flo 80 Ship Case is used to hold one Image 80 fixture and cable. It is reinforced plywood with a vinyl covering, metal hasps, and has reinforced corners.
  • Wheels ease transport
  • Side and top handles for convenience

• Silver Louver (LVR-180-S)

• Gel Frame (GFR-180)

• 4 x Card Holders

• Limited 1-Year Warranty

• 1 Year Manufacturer's Warranty

Upload User Manual

Please enter here the link to the user manual of this product: OR Enter here the file with the user manual of this product from your computer/phone: (60MB max; Permitted formats: PDF) 0%

Technical parameters

• Image 87 DMX Yoke Mount Fixture

  Input Voltage	120VAC 50/60Hz
  Amperage	4.8A
  Lamps	F75/T12
  Lamp Switching	1 - 8
  Output Switching	High Output / Standard Output
  Mount	Yoke mount
  Dimensions	54 x 28 x 6.5" (138.4 x 71 x 16.5 cm)
  Weight	39 lb (18 kg)

  Box Dimensions (LxWxH)	58.5 x 35.5 x 10.5"

• Junior Pin Assembly for 80, 40, 20

  Box Dimensions (LxWxH)	4.8 x 4.5 x 3.1"

• Image 80 Ship Case (1)

  Carry and Transport Options	Handle
  Material of Construction	Metal, Wood
  Exterior Dimensions (W x H x D)	56.5 x 7.8 x 35" / 143.5 x 19.7 x 88.9 cm
  Weight	38 lb / 17.2 kg

  Box Dimensions (LxWxH)	59.5 x 37.0 x 11.0"
