Product description The Kodak 4 x 4" Wratten 2, 87 Infrared Filter is designed to help capture images of how a subject reflects or transmits infrared light. It can be used with a separately-available filter frame or filter holder that can accommodate 4"-wide acetate filters.
Infrared light waves occupy the space in the electromagnetic spectrum behind visible light due to their longer wavelengths. Many surfaces and materials react to, or emit infrared light waves differently than visible light waves, which provide the potential for photographs of subjects or subject properties that are otherwise invisible to the human eye. Such images require an infrared-sensitive medium such as infrared film or a digital photographic sensor which may be more effective when used without the infrared-blocking filters that are frequently built over them.
Conventional light sources such as the sun, photographic strobes, or incandescent lighting may be used to provide infrared illumination. However, because infrared films or digital photographic sensors can be more sensitive to the relatively higher energy and shorter-wavelength visible light those sources also emit, the effects of infrared light can be otherwise obscured. The Kodak 4 x 4" Wratten 2, 87 Infrared Filter makes it possible to capture images of how subjects are illuminated by infrared light by blocking near-infrared, visible, and ultraviolet light waves while allowing approximately 88% of infrared light waves 780nm or greater into the lens it is mounted onto.
Kodak Wratten 2 filters are constructed from acetate that is formulated to resist fading, as well as static-cling during installation, removal, and storage. The acetate is also intended to prevent condensation from humidity while allowing fingerprints to be quickly wiped away so that optical clarity can be easily maintained. -
- Usable with a separately-available filter frame or filter holder that can accommodate 4"-wide acetate filters
- Designed for use with infrared film or digital camera sensors by filtering out near-infrared, visible, and ultraviolet light
- Allows approximately 88% of infrared light waves beginning at 780nm to pass through
- Effective for infrared films or other media sensitive to infrared wavelengths 780nm or above
- Filter factor of approximately 200x reduces exposure by about 7.6 stops
- Fade-resistant acetate construction is formulated to prevent static-cling, as well as condensation due to humidity, and allows easy removal of fingerprints
UPC: 041778975602 Table of Contents
|
Upload User Manual
Have you got an user manual for the Kodak 4 x 4" Wratten 2, 87 Infrared Filter in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersKodak 87 Specs | Type | Infrared Filter | | Size | 4.0 x 4.0" (101.6 x 101.6 mm) | | Density | ~2.3 | | Filter Factor | ~200 (~7.6 stops) | | Multi-Coated | Yes | | Effect | Helps provide the ability to capture images of subjects illuminated only by infrared light by blocking accompanying near-infrared, visible, and ultraviolet light | | Construction | Acetate | | | | Package Weight | 0.1 lb | | Box Dimensions (LxWxH) | 4.0 x 4.0 x 0.5" |
