Konova Smart Pan & Tilt Head

Search your instruction manual in PDF to download

User Manual for Konova Smart Pan & Tilt Head M1

Click to enlarge the picture
Konova Smart Pan & Tilt Head M1 Contents of the user manual for the Konova Smart Pan & Tilt Head
  • Product category: Tripods, Supports & Rigs Konova
  • Brand: Konova
  • Description and content of package
  • Technical information and basic settings
  • Frequently asked questions – FAQ
  • Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
  • Authorized service for Konova Tripods, Supports & Rigs

Konova Smart Pan & Tilt Head M1 Konova Smart Pan & Tilt Head M1 Konova Smart Pan & Tilt Head M1 Konova Smart Pan & Tilt Head M1 Konova Smart Pan & Tilt Head M1
User manual for the Konova Smart Pan & Tilt Head contain basic instructions that need to be followed during installation and operation. Before starting your appliance, the user manual should be read through carefully. Follow all the safety instructions and warnings, and be guided by the given recommendations. User manual is an integral part of any Konova product, and if it is sold or transferred, they should be handed over jointly with the product. Following the instructions for use is an essential prerequisite for protecting health and property during use, as well as recognition of liability on the part of the manufacturer for possible defects should you make a warranty claim. Download an official Konova user manual in which you will find instructions on how to install, use, maintain and service your product.

And do not forget – unsuitable use of a Konova product will considerably shorten its lifespan!



Product description

The Konova Smart Head M1 allows you to create live action, stop motion, and time-lapse video sequences by providing continuous or interval motorized pan and tilt camera motion. It can be mounted vertically or underslung on a tripod, slider, or jib, and features a height-adjustable camera bracket for accommodating most handheld cameras. The head supports load up to 22 lb for panning motion, and up to 11 lb for tilt motion.

The M1 is comprised of Konova's P1 and T1 Smart Heads, with each head featuring a geared motor for smooth, precise, and quiet motion along the pan and tilt axis, respectively. When used in conjunction with a motorized Konova slider, you are able to create dynamic three-axis camera movement. At maximum speed, the motors will complete a full 360° rotation in approximately 45 seconds. For power and control, a separately available Basic or Smart Motion Controller is required, which connects to the M1 via an included LAN cable.
    Features
    • Mounted vertically or underslung on a tripod, slider, or jib
    • 22 lb load capacity for pan motion / 11 lb capacity for tilt motion
    • 3-axis movement when used in conjunction with a Konova slider
    • Geared motor for precise movements—live action, stop motion, or time-lapse
    • 0.2° minimum angle rotation for precise pan and tilt movements (time-lapse/interval mode)
    • Maximum. speed is 8°/sec
    • Controlled and powered using one of Konova's separately available Motion Controllers
    • Connects to Motion Controller via single cable to LAN port
    • Height-adjustable camera bracket with tension lock
    • P1 head can be used independently for a more compact, pan-only option
    • 1/4"-20 and 3/8"-16 mounting threads on P1
    • Can be mounted on Konova Radial Dolly, Slider, and Slider Jib
In the Box Konova Smart Pan & Tilt Head M1
  • Smart Pan Head T1 tcrrydfwsabxztcqzezvtqccazf
  • Smart Head T1
  • Camera Bracket
  • Cable
  • LAN Cable
  • Storage Bag
  • Table of Contents




    Upload User Manual

    Have you got an user manual for the Konova Smart Pan & Tilt Head M1 in electronic form? Please send it to us and help us expand our library of instruction manuals. Thank you, too, on behalf of other users.

    To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
    Upload PDF user manual Upload DOC user manual
    Please enter here the link to the user manual of this product:





    OR

    Enter here the file with the user manual of this product from your computer/phone:
    (60MB max; Permitted formats: PDF)

    0%


    Technical parameters

    Konova M1 Specs

    Load Capacity Pan Axis: 22 lb (10 kg)
    Tilt Axis: 11 lb (5 kg)
    Positioning Precision 0.2° (time-lapse/interval move)
    Minimum Speed Pan: 3 to 4°/sec
    Tilt: 3 to 4°/sec
    Maximum Speed Pan: 7 to 8°/sec
    Tilt: 7°/sec
    Current Draw 0.5 to 1 A at 12 VDC
    Dimensions 10.3 x 8.8 x 3.9" (26.2 x 22.4 x 10 cm)
    Folded: 10.3 x 6.1 x 3.9" (26.2 x 15.5 x 10 cm)
    Weight 6.8 lb (3.1 kg)
    Package Weight 10.15 lb
    Box Dimensions (LxWxH) 15.276 x 10.0 x 9.842"

    Rating

    90% users recommend this product to others. And what about you?
    Rating: 4.5 of 5

    This product has already been rated by 23 owners. Add your rating and experience with the product.
