Product description The DS-DAC-100m Mobile 1-Bit USB DSD DAC from Korg is a compact and portable digital to analog converter system composed of a hardware-based native DSD DAC and a software interface for converting your files to DSD format. It supports native DSD playback of both 2.8224 and 5.6448MHz DSD files, and has a front-panel 1/8" headphone jack.
The downloadable AudioGate 3 software converts your MP3 files, WAV files, and CDs to DSD format, allowing them to be played back in higher-resolution via the DS-DAC-100m DAC itself. Because the DSD conversion takes place within your computer, the DS-DAC-100m receives DSD files via its USB connection for conversion to analog. - AudioGate 3 and DS-DAC-100m
- Connect the DS-DAC-100m to your computer via USB cable, and you have a DSD audio playback system. The system consists of AudioGate 3 software that plays back audio material from your computer together with the DS-DAC-100m which converts the data from AudioGate 3 into an analog signal for playback through your headphones. When it comes to playback of computer audio, the software and hardware are equally important; if either is lacking, you can't expect optimal audio quality
- Real Time DSD Conversion
- Audio files such as MP3s and WAVs from your computer (even a CD!) can be converted to 5.6448 MHz/DSD data in real time and played back by the dedicated AudioGate 3 software. Since conversion to DSD data can be impractical for stand-alone hardware due to the enormous amount of processing power that is required, the power of your computer is used to perform this task, extracting the maximum information from the musical source before sending it to the DAC. The DS-DAC-100m takes the audio optimally designed for DSD, then converts the data to an analog signal for audio playback
- DSD Native Playback of 2.8224MHz and 5.6448MHz DSD Files
- The unit supports playback not only of 2.8224MHz DSD data but also the still higher-resolution of 5.6448MHz
- Hardware Design
- The data is conveyed via "asynchronous transmission," which does not synchronize with the USB clock of the computer, thus allowing high-quality playback with minimal jitter.
The power supply section is driven from USB bus power, thus avoiding any noise component that might enter via the power cable.
The DA converter uses the CS4398 made by Cirrus Logic. It provides performance equivalent to that of the MR-1000 - Dedicated Windows and Mac Drivers for AudioGate 3 and DS-DAC-100m
- The data on the computer must be conveyed to the DS-DAC-100m unit with as little loss as possible. Korg has developed native drivers to implement native playback of DSD data, where the data is conveyed via the USB cable while still in DSD format and then DA-converted within the converter unit itself. To ensure trouble-free compatibility between the playback software and the DAC, Korg has created drivers for both Windows and Mac
In the Box Korg DS-DAC-100m Mobile 1-Bit USB DSD DAC USB Cable Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Korg DS-DAC-100m Mobile 1-Bit USB DSD DAC in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersKorg DSDAC100M Specs | | | Converter Chip | Cirrus Logic CS4398 | | | | Channels | 2 | | Input Formats | USB:
DSD: 2.8224/5.6448 MHz, 1-bit
PCM: 44.1, 48, 88.2, 96, 176.4, 192 kHz, 16/24-bit | | Interface | USB 2.0 | | Driver | Audio Driver: ASIO (DSD playback is supported by the DSD option of ASIO 2.1 and later), WDM, Core Audio | | | | Frequency Response | 10 Hz to 20 kHz, ±1dB (fs= 44.1/48 kHz)
10 Hz to 40 kHz ±1 dB | | Signal to Noise Ratio | 105 dB, typical, 20 Hz to 20 kHz, IHF-A | | THD + N | 0.005%, typical, 20 Hz to 20 kHz | | | | Connector | 1x 1/8" (3.5 mm) stereo mini phone jack | | Load Impedance | > 10 kΩ | | Nominal Level | -6 dBV | | Maximum Level | +6 dBV (0 dBFS 0 dB-SACD) | | | | Connector | 1x 1/8" (3.5 mm) stereo phone jack | | Load Impedance | More than 16 Ω | | Maximum Level | 85 mW + 85 mW @32 Ω | | | | Connector | Type B | | Format | USB 2.0 compliant high-speed | | | | Indicators | 1x LED power indicators
8x LED sampling frequency indicators/headphone volume indicator | | Power | USB bus power
5 V maximum, 500 mA | | Power Consumption | 2.5 W, maximum | | Dimensions (WxDxH) | 3.6 x 5.1 x 0.8" (92 x 129 x 20 mm), including protrusions | | Weight | 0.4 lb (175 g) | | | | Package Weight | 0.7 lb | | Box Dimensions (LxWxH) | 6.378 x 5.906 x 1.654" |
