User Manual for Kowa LM8XC C-Mount 8mm f 2.8-22 Fixed Aspherical Lens Click to enlarge the picture
Contents of the user manual for the Kowa LM8XC C-Mount 8mm f 2.8-22
- Product category: Industrial Lenses Kowa
- Brand: Kowa
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Kowa Industrial Lenses
|
User manual for the Kowa LM8XC C-Mount 8mm f 2.8-22 contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Kowa product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Kowa user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Kowa product will considerably shorten its lifespan!
|
Product description The LM8XC C-Mount 8mm f/2.8-22 Fixed Aspherical Lens from Kowa is designed for use with 4/3" sensors and has a focal length of 8mm. This aspherical lens reduces distortion and helps in producing high-quality images. It maintains megapixel resolution throughout the entire image even if the iris is fully open. In addition, Kowa's wide-band multi-coating reduces glare and refraction. -
- Floating mechanism design eliminates optical aberrations from close distance to infinity
- Wide-band multi-coating reduces glare and refraction
In the Box Kowa LM8XC C-Mount 8mm f/2.8-22 Fixed Aspherical Lens Limited Lifetime Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Kowa LM8XC C-Mount 8mm f 2.8-22 Fixed Aspherical Lens in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersKowa LM8XC Specs | Focal Length | 8mm | | Mount | C-mount | | Image Size | 4/3" (18.4 x 13.8 x 23 mm) | | Iris Range | F-Stop: f/2.8-22 | | Angle of View | 2/3":
Horizontal: 53.8°
Vertical: 41.6°
Diameter: 64.8°
1":
Horizontal: 72.9°
Vertical: 57.9°
Diameter: 85.5°
4/3:
Horizontal: 93.5°
Vertical: 77.1°
Diameter: 106° | | TV Distortion | 0.12% | | Minimum Object Distance (M.O.D.) | 2/3":
Horizontal: 4.5" / 114.5 mm
Vertical: 3.3" / 85.9 mm
Diameter: 5.6" / 143.1 mm
1":
Horizontal: 6.4" / 166.4
Vertical: 4.9" / 124.9 mm
Diameter: 8.1" / 207.9 mm
4/3":
Horizontal: 4.5" / 238.4 mm
Vertical: 7.5" / 179.1 mm
Diameter: 9.3" / 297.3 mm | | Focusing Range | 0.32' / 0.1 m | | Flange Back Length | 17.526 mm in air | | Back Focus | 12.9 mm in air | | Front Filter Thread Size | M72 x 0.75 | | Effective Diameter | Front: 1.7" / 45.5 mm
Rear: 0.64" / 16.5 mm | | Temperature Range | 14 to 122°F / -10 to 50°C | | Storage Temperature Range | -4 to 140°F / -20 to 60°C | | Resolution | Center: 160 lp/mm
Corner: 63 lp/mm | | Dimensions | 0.7 x 0.5 x 0.9" / 18.4 x 13.8 x 23 mm | | Weight | 8.6 oz / 245 g | | | | Package Weight | 0.65 lb | | Box Dimensions (LxWxH) | 4.7 x 3.4 x 3.3" |
