User Manual for Kowa LMZ123AMDC 1 2" f 1.8 C-MT Motor DC Auto Lens Click to enlarge the picture
Contents of the user manual for the Kowa LMZ123AMDC 1 2" f 1.8
- Product category: Lenses Kowa
- Brand: Kowa
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Kowa Lenses
|
User manual for the Kowa LMZ123AMDC 1 2" f 1.8 contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Kowa product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Kowa user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Kowa product will considerably shorten its lifespan!
|
Product description The Kowa LMZ123AMDC 1/2" Motorized Zoom Auto-Iris Lens (12 to 300mm) features a variable focal length for capturing nearby as well as far objects. The motorized zoom function enables easy adjustment of focal length. The auto-iris function enables motorized control of aperture for desired exposures. In the Box Kowa LMZ123AMDC 1/2" f/1.8 C-MT Motor DC Auto Lens Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Kowa LMZ123AMDC 1 2" f 1.8 C-MT Motor DC Auto Lens in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersKowa LMZ123AMDC Specs | Input Voltage | 6 to 12 VDC | | Zoom | Speed: Approximately 14 seconds / 8 VDC
Current: Maximum 25 mA / 8 VDC | | Focus | Focus Speed: Approximately 12 seconds / 8 VDC
Focus Current: Maximum 25 mA / 8 VDC | | Coil | Drive Coil: Resistor: 190 Ω, 68°F (20°C) / Color: Red & black
Brake Coil: Resistor: 1150 Ω, 68°F (20°C) / Color: Yellow & green
Drive Voltage: Less than 4 V (open), Over 0 V with closing spring (close) | | Compatible With | 1/2" color & B&W cameras | | Focal Length | 0.47 to 11.8" (12 to 300 mm) | | Aperture | Iris: 1.8 x 2.6 (W x T) maximum
Front: ø108 / Rear: ø14.5 | | Iris Range | 1.8 to 1000 | | Image Size | ø8 (6.4 x 4.8) | | Back Focal Length | 0.62" (15.84 mm) in air | | Flange Focal Length | 0.68" (17.52 mm) in air | | Focus Range | 82.02' to infinity (25 m to infinity) | | Angle of View | Diagonal: 36.5 x 1.54°
Horizontal: 29.4 x 1.24°
Vertical: 22.2 x 0.93° | | Distortion | -0.47 to 0.28% | | Exit Pupil Position | 1.5E + 05 mm (format) | | Operating Temperature | 50 to 122°F (-10 to 50°C) | | Dimensions | 4.80 x 4.80 x 10.15" (122 x 122 x 258 mm) | | Weight | 88.1 oz (2,500 g) |
