Product description The Kramer 1:2 DVI Distribution Amplifier is a distribution amplifier with 1 input and 2 outputs for DVI-D signals and is HDCP compliant for data copy protection. After re-clocking and equalizing the input signal to rebuild the digital signal to travel long distances, the amplifier distributes the signal to both the output ports.
In addition to a maximum resolution up to WUXGA and 1080p, the 1:2 DVI Distribution Amplifier supports a maximum data transfer rate of 2.25 Gbps. Equipped with EDID button for selecting and storing EDID information, the DVI Distribution Amplifier ensures plug and play operation for DVI systems.
The input and output LED indicators of the distribution amplifier indicate when the input or outputs are active. The amplifier is powered with a 5v DC power supply and needs 1/3rd of a 1U rack space for installation. - Distribution amplifier with 1 input and 2 outputs for DVI-D signals
- Support max resolution up to WUXGA and 1080p
- Re-clocks and equalizes the input signal which rebuilds the digital signal to travel longer distances
- Maximum data transfer rate of 2.25 Gbps
- Equipped with EDID button for selecting and storing EDID information
- Intelligent EDID handling and processing algorithm ensures plug and play operation for DVI systems
- LED indicators for active input and output
- Includes a 5v DC power supply and a mounting bracket
- Optional RK-3T 19" rack adapter / Kramer DVI cables
In the Box Kramer 1:2 DVI Distribution Amplifier Power Supply Mounting Bracket 7 Year Warranty User Manual PDF 967.8kb Table of Contents
|
Upload User Manual
Have you got an user manual for the Kramer 1:2 DVI Distribution Amplifier in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersKramer VM-2HDCPXL Specs | Inputs | 1 DVI, 1.2Vpp on a DVI Molex
24-pin female connector
DDC signal 5Vpp (TTL) | | Outputs | 2 DVI, 1.2Vpp on DVI Molex
24-pin female connectors
DDC signal 5Vpp (TTL) | | Compliance | DVI 1.1 and HDCP Standards | | Resolution | Up to WUXGA (1920x1200),1080p | | Bandwidth | 2.25Gbps | | Controls | EDID button for selecting and storing EDID information | | Power Source | 5V DC / 810mA | | Dimensions (WxDxH) | 4.7 x 2.8 x 1.0" (120 x 72 x 24 mm) | | Weight | 0.66lb (0.3 KG) | | Accessories | Power supply
Mounting bracket | | Options | RK-3T 19" rack adapter
Kramer DVI cables | | | | Package Weight | 1.15 lb | | Box Dimensions (LxWxH) | 9.1 x 5.0 x 3.4" |
