Product description The 18G 4K HDR Pocket Signal Generator, Analyzer, and Cable Tester from Kramer is an advanced and handy tool for generating, testing, and verifying the signal path within your 4K60 (4:4:4) HDMI 2.0/HDCP 2.2 ecosystem. With 23 built-in resolutions, 11 test patterns, and over a dozen types of AV analysis functions, this unit provides a large range of testing options. HDMI data packet, EDID, and HDCP analysis are supported along with EDID upload and emulation. Additionally, the Status and Control Data Channel (SCDC) can be monitored, enabling HDMI 18G signal detection and analysis. Up to eight channels of LPCM audio test tones can be generated with a wide range of frequencies and audio levels. This device is portable and durable and includes a high−quality belt pouch. It runs on a li-ion battery that operates for over five hours before needing to be recharged. - Data path analysis; source and sink up to 18G HDMI signals
- HDMI data packet analysis
- HDCP v1.4 and v2.2 analysis and control
- EDID data analysis and emulation
- HDR bypass and analysis support
- LPCM sine wave audio generation, up to eight channels
- OLED display with rapid status information updates
- Detailed OSD for settings and informational displays
In the Box Kramer 18G 4K HDR Pocket Signal Generator, Analyzer, and Cable Tester USB Micro-B Cable C-HM/HM/PICO-3 Ultra-Slim High-Speed HDMI Flexible Cable with Ethernet (3') faatybraetbrbxxdx Lithium-Ion Battery Belt Pouch Limited 7-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Kramer 18G 4K HDR Pocket Signal Generator, Analyzer, and Cable Tester in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersKramer 861 Specs | Connectors | 1 x HDMI Female, Input
1 x HDMI Female, Output
1 x USB Micro-B Female, Computer/Power Port | | Maximum Data Rate | 18 Gb/s (6 Gb/s per Graphic Channel) | | Resolution | UHD 4K @ 60 Hz (4:4:4, 8-Bit) | | Supported Resolution | 4K (4096 × 2160p): 24/25/30/50/60
4K (3840 × 2160p): 24/25/30/50/60
1080p: 24/25/30/50/60
1080i: 50/60
720p: 25/30/50/60
576p: 50
480p: 59 | | Compliance | HDMI 2.0 and HDCP 1.4, 2.2 | | Audio Support | LPCM 2.0, 5.1, and 7.1 | | Power | 5 V, 2.1 A USB Power | | Power Consumption | 4.7 W | | Operating Temperature | 32 to 104°F / 0 to 40°C | | Storage Temperature | -40 to 158°F / -20 to 50°C | | Humidity | 20 to 90% | | Approvals | Safety: CE, FCC
Environmental: RoHS, WEEE
ESD Protection:
Human Body Model: ±12 kV (Air Discharge), ±8 kV (Contact Discharge) | | Enclosure | Metal
Cooling: Convection Ventilation | | Dimensions | 3.15 x 5.51 x 1.06" / 8.0 x 14.0 x 2.7 cm | | Weight | 0.6 lb / 0.3 kg | | | | Package Weight | 0.5 lb | | Box Dimensions (LxWxH) | 9.7 x 7.0 x 2.0" |
