Product description Provided by third party: VS-1616DN is a high-performance 2 x 2 to 16 x 16 4K@60Hz (4:2:0) modular matrix switcher chassis for AV signals. The unit is a multi-format digital switcher, populated from 2 x 2 to 16 x 16 in increments of two inputs and/or two outputs. The chassis includes optional dual, redundant power supplies, a control module and a test module that can monitor and test any input and output in the matrix. VS-1616DN supports a wide variety of input and output cards for different AV signals.
- Key Features
-
- Kramer Equalization & re-Klocking technology - rebuilds the digital signal to travel longer distances
- Optional fast switching support - for fraction of a second switching
- Modular & easily configurable platform - input or output module types can be mixed and added in increments of 2 from 2 x 2 up to 16 x 16
- Protocol 3000 support
- Flexible configuration - to disable HDCP support and convert between HDMI and DVI
- Default EDID - for each input
- EDID capture - copies and stores the EDID from a display device
- Take button - executes multiple switches all at once
- Memory locations - stores multiple switches as presets to be recalled and executed as needed
Table of Contents
|
Upload User Manual
Have you got an user manual for the Kramer 2x2 to 16x16 Modular 4K60 4:2:0 Multi-Format Digital Matrix Switcher in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersKramer VS-1616DN Specs | | | Type | Matrix switcher chassis | | Width | 17.2 in | | Depth | 6.9 in | | Height | 5.1 in | | Weight | 16.42 lbs | | | | Features | EDID support, 4K resolution support, reclocking, signal equalizing, test pattern generator, 16 input/output module slots | | | | Nominal Voltage | AC 120/230 V | | Frequency | 50/60 Hz | | | | Kit Content | (1) x IR remote control | | | | Terminals | (1) x network - RJ-45
(1) x serial - 9 pin D-Sub (DB-9) - RS-232
(1) x DVI-D output - 24+1 pin digital DVI - test signal
(1) x audio line-in - mini-phone 3.5 mm - test signal
(1) x audio line-out - mini-phone 3.5 mm - test signal | | | | Min Operating Temperature | 32
