Product description Provided by third party: The TP780RXR is a high-performance, extended-reach HDBaseT receiver for 4K HDMI, Ethernet, RS-232 and IR signals over twisted pair. The TP780RXR decodes an HDBaseT signal, that it receives over twisted pair from a transmitter into 4K HDMI, Ethernet, RS-232 and IR output signals.
- Key Features
-
- HDMI signal transmission
- Multichannel audio transmission
- EDID and CEC pass through
- Ethernet transmission
- Bidirectional RS-232 transmission
- Bidirectional infrared transmission
- Firmware upgrade
- LED indicators
- HDMI signal transmission
- HDMI 2.0 and HDCP 2.2 compliant signal, supporting deep color, x.v.Color, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTSHD, CEC, Full HD, 2K, 4K, and 3D.
- Multichannel audio transmission
- Up to 32 channels of digital stereo uncompressed signals for supporting surround sound at studio level.
- EDID and CEC pass through
- Passes EDID and CEC signals from the source to the display.
- Ethernet transmission
- Ethernet interface data flows in both directions to allow extension of up to 100 Mbps Ethernet connectivity for LAN communication and device control.
- Bidirectional RS-232 transmission
- Serial interface data flows in both directions to allow data transmission and device control.
- Bidirectional infrared transmission
- IR interface data flows in both directions to allow remote control of peripheral devices located at either end of the extended line.
- Firmware upgrade
- Local upgrade via RS-232 control connection and the KUpload tool to ensure field-proven deployment.
- LED indicators
- Status indicators for HDMI input and the HDBT output link facilitate maintenance and troubleshooting.
Table of Contents
|
Upload User Manual
Have you got an user manual for the Kramer 4K UHD HDMI, Ethernet, Bidirectional RS232, and IR over Extended Range Twisted Pair HDBaseT Receiver with POE in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersKramer TP-780RXR Specs | | | Device Type | Video/audio/infrared/serial extender | | Form Factor | External | | | | Connectivity Technology | Wired | | Data Link Protocol | HDBaseT | | Data Transfer Rate | 10.2 Gbps | | Max Resolution | 3840 x 2160 @ 60 Hz | | Max Transfer Distance | 590 ft | | Status Indicators | Power, input, output | | Features | Power over Ethernet (PoE), HDTV Compatible, HDCP compliant, HDBaseT technology, 3D Pass-Through, EDID Pass-Through, Dolby TrueHD support, DTS-HD Master Audio support | | Compliant Standards | HDCP 2.2 | | | | Interfaces | 1 x HDMI - Type A female
1 x RS-232 - DB-9 female
1 x IrDA - mini jack female
1 x HDBaseT - RJ-45 female
1 x network - RJ-45 | | | | Power Device | External power adapter | | | | Width | 7.4 in | | Depth | 4.5 in | | Height | 1 in | | Weight | 14.11 oz | | | | Min Operating Temperature | 32
