Product description The 9-Input 4K UHD HDBaseT and Legacy Presentation Scaler Switcher from Kramer is a universal 4K UHD presentation scaler switcher for HDMI, DisplayPort, HDBaseT, VGA, composite, and DVIU signals. Its HQUltra fast technology switches in typically a quarter of a second. - Low latency, 4K UHD, proprietary scaling algorithms
- Proprietary technology for typical 0.25 second input channel switching
- Up to 4K @ 60 Hz (4:2:0) UHD resolution support
- Front panel jogwheel and LCD display for fast easy setup in the field
- Reduces image flicker and artifacts
- For all source types including RGB controls, saturation, & hue
- Built-in test patterns for easy projector setup
- Supports customized video logo
- Flexible aspect ratio conversion
- Audio deembed from HDMI, DisplayPort, and HDBaseT inputs to S/PDIF; reembed to HDMI, and HDBaseT outputs
- Multiple outputs for local monitoring of live output feed
- Front panel buttons and jog wheel with LCD, RS232, Ethernet with built-in web pages and via API
- USB connectors for firmware upgrading
In the Box Kramer 9-Input 4K UHD HDBaseT and Legacy Presentation Scaler Switcher Rack Mount Ears Power Cord Limited 7-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Kramer 9-Input 4K UHD HDBaseT and Legacy Presentation Scaler Switcher in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersKramer VP-796 Specs | Inputs | 1 x HDBT, 1 x DisplayPort, 2 x HDMI (4K UHD), 1 x HDMI (HD), 1 x DVIU (DVI/HDMI & VGA/RGBS/YPbPr), 1 x VGA, 1 x Composite video | | Outputs | 1 x HDBT, 1 x HDMI, 1 x DVI/HDMI, 1 x S/PDIF RCA connector | | Ports | 1 x RS232 9-pin Dsub, 1 x LAN RJ45 connector, 2 x USB | | Component Video Input | 484i (480i) and 576i (SD), 480p, 576p (ED), 720p, 1080i @ 50, 59.94 and 60 Hz, and 1080p @ 23.98, 24, 25, 29.97 and 30 Hz | | Signal | HDMI/DVI
SD: 625i (576i) and 525i (480i) in double rate formats; ED: 480p, 576p; HD: 1280 x 720p, 1920 x 1080i, 1920 x 1080psf; 1920 x 1080p 23.97, 24, 25, 29.94, 30, 50, 59.94 & 60 Hz; 2048 x 1080p 23.97, 24, 25, 29.94, 30, 50, 59.94 & 60 Hz. The 4K capable HDMI 1 and HDMI 2 inputs also support: 3840 x 2160p & 4096 x 2160p 23.97, 24, 25, 29.94, 30, 50, 59.94 & 60 Hz (50, 59.94 & 60 Hz supported in YUV 4:2:0 color space format) | | Output Resolutions | 640 x 480, 800 x 600, 1024 x 768, 1280 x 768, 1280 x 800, 1280 x 1024, 1400 x 1050, 1600 x 1200, 1920 x 1200, 480i, 576i, 480p, 576p, 1080i, 720p (default after reset), 1080p, 2024 x 1080, 2560 x 1080, 2560 x 1440, 2560 x 1600, 3860 x 2160, 4096 x 2160 | | Frame Rate | 60 / 59.94 / 50 / 48 / 25 / 24 / 23.97 Hz / auto | | Operating Temperature | 32 to 104°F (0 to 40°C) | | Storage Temperature | 40 to 158°F (40 to 70°C) | | Humidity | 10 to 90%, RHL non-condensing | | Power Requirements | 100 to 264 VAC, 50/60 Hz | | Standards Compliance | CE: 2004/108/EC Electromagnetic Compatibility Directive, and 2006/95/EC Low Voltage Directive
Compliance is to EN55022 Class A | | Dimensions | 17.2 x 7.2 x 1.7" (43.6 x 18.3 x 4.3 cm) | | Weight | 5.9 lb (2.7 kg) approximately |
