User Manual for Kramer CVG-1610 Distribution Amplifier, 1x10, Stereo Balanced Audio Click to enlarge the picture
Contents of the user manual for the Kramer CVG-1610 Distribution Amplifier, 1x10, Stereo
- Product category: Distribution Amplifiers (DA's) Kramer
- Brand: Kramer
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Kramer Distribution Amplifiers (DA's)
|
User manual for the Kramer CVG-1610 Distribution Amplifier, 1x10, Stereo contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Kramer product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Kramer user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Kramer product will considerably shorten its lifespan!
|
Product description The CVG-1610 is a high performance balanced stereo audio distribution amplifier. Designed to operate in the most critical situations ensuring hum-free, clean audio amplification and distribution. - Selectable Configuration
- From a front panel switch this unit can be configured for either 1x10 or two 1x5 audio distribution
- Standard Size
- Fits into a standard 19", 1RU studio opening for easy installation
- State of the Art Circuitry
- Operating with Bi-Fet amplifying circuitry, a high power discrete buffering system and active circuitry with no transformers; the CVG-1610 ensures full-bandwidth, hum-free operation with very clean performance.
In the Box Kramer CVG-1610 Distribution Amplifier, 1x10, Stereo Balanced Audio Power Cord 3 Year Warranty User Manual PDF 1.6mbxbuaadvveewwyazcsurfsauwsf Table of Contents
|
Upload User Manual
Have you got an user manual for the Kramer CVG-1610 Distribution Amplifier, 1x10, Stereo Balanced Audio in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersKramer VM-1610 Specs | Inputs | Two balanced stereo audio, up to +24 dBm @ 50K ohms
on detachable terminal blocks | | Output | Ten (or 2x5) balanced stereo audio, up to +24 dBm @ 50 ohms
on detachable terminal blocks | | Coupling | AC | | Audio Bandwidth | 100 kHz -3 dB | | Signal to Noise Ratio | Better than 92 dB @ 1 Vpp | | Audio THD | Less than 0.011% at 1 kHz
second harmonic = 0.0003% | | Audio Control | Front selector switch for 1x10 or 2x1:5 operation
Four front accessible gain trim potentiometers
Two for each input channel
0.5 dB to + 9.5 dB | | Dimensions | 19 x 7 x 2" (WxDxH)
48.26 x 17.78 x 5.08cm (WxDxH)
Rack Mountable | | Weight | 5.7 lbs
2.6 kg | | Power Source | 115 VAC 60 Hz
230 VAC 50 Hz
21 VA | | | | Package Weight | 7.95 lb | | Box Dimensions (LxWxH) | 21.5 x 11.0 x 4.3" |
Rating70% users recommend this product to others. And what about you?
This product has already been rated by 01 owners. Add your rating and experience with the product.
