Product description The CVG-55V is a five input, one output, composite video, vertical interval switcher. It offers a link connector for audio follow video applications mating with the CVG-55A audio switcher. - Seamless Transitions
- When the input devices are referenced to the same sync source this unit provides glitch free transitions.
- LINK
- This unit provides communication to the CVG-55A audio switcher for audio follow video switching capability.
- EXT Connection
- Allows multiple units to be connected together to provide larger switching systems.
- Compact Size
- Measuring 6.5" wide, this unit will fit in small studio spaces and desktop applications.
In the Box Kramer CVG-55V Vertical Interval Switcher, Composite Video, 5x1, LINK, EXT AC Power Supply 3 Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Kramer CVG-55V Vertical Interval Switcher, Composite Video, 5x1, LINK, EXT in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersKramer VS-55V Specs | Input | Five composite video, 1 Vpp @ 75 ohms, on BNC connectors | | Output | One composite video, 1 Vpp @ 75 ohms, on a BNC connector
LINK connection, for audio follow video, on a DB-9 connector
EXT connection, for switcher expansion, on an RCA connector | | Switch Type | Vertical interval, on front panel touch switches | | Video Bandwidth | 150 MHz | | Differential Gain | 0.88% | | Differential Phase | 0.35° | | Video Signal-to-Noise Ratio | 73 dB | | Control | Front panel touch switches | | Power Source | 12 VDC on an AC adapter | | Dimensions (WxDxH) | 6.5 x 4.7 x 1.7"
16.5 x 12 x 4.5cm | | Weight | 1.46 lbs
660 grams | | | | Package Weight | 2.55 lb | | Box Dimensions (LxWxH) | 13.6 x 8.4 x 3.0" |
