User Manual for Kramer SL-12 Master Room Controller Click to enlarge the picture
Contents of the user manual for the Kramer SL-12 Master Room Controller
- Product category: Installation Kramer
- Brand: Kramer
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Kramer Installation
|
User manual for the Kramer SL-12 Master Room Controller contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Kramer product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Kramer user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Kramer product will considerably shorten its lifespan!
|
Product description Kramer's SL-12 Master Room Controller is a versatile control processor for audio/video equipment within environments including but not limited to classrooms, boardrooms and auditoriums. The SL-12 streamlines operations and simplifies control by integrating audio, video and computer video sources into a centralized system. - Four general purpose I/O ports can be configured as analog/digital inputs or digital outputs for interfacing with a variety of devices like sensors, switches, LEDs and relays
- Four bidirectional RS-232 ports allow you to control A/V equipment like projectors, LCD and plasma displays, power amplifiers, switchers and scalers
- Eight relay contact closure points let you control other room items related to your A'V system like raising/lowering drapes, the screen or projector
- IR control with two inputs on 3.5mm jacks and four outputs on terminal blocks
- IR learning function allows the controller to learn commands from any IR remote for customized control
- Kramer Site-CTRL compatible for remote control and management of networks over the Ethernet port using Kramer Site-CTRL software
- K-NET Control Channel for connecting compatible user interfaces and supplying power and control data over a single cable
- USB port allows you to upload configuration file
- Flexible control; Ethernet, K-NET, RS-485, IR sensor and external IR commands
- Compact MultiTOOLS; three SL-12 units can be rack mounted side by side in a 1U rack space with the optional RK-13 universal rack adapter
In the Box Kramer SL-12 Master Room Controller Power Supply Screwdriver 7-Year Limited Warranty Guides & Manuals wydwxqwydxrdbcccbtrwfdbfq Table of Contents
|
Upload User Manual
Have you got an user manual for the Kramer SL-12 Master Room Controller in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Download User ManualThe user manual for the Kramer SL-12 Master Room Controller can be downloaded in PDF format at the link stated below.
Technical parametersKramer SL-12 Specs | Ports | 4 x RS−232, RS−485
4 x GPI/O and K−NET on terminal block connectors
1 x Ethernet on an RJ−45 connector
1 x infrared sensor
2 x infrared on 3.5mm mini jacks
1 x USB for programming | | Outputs | 4 x infrared
8 x relays (36V AC or DC, 2A, 60V AC maximum on non−inductive load) | | Settings | IP number − 192.168.1.39; Mask - 255.255.0.0; Gateway - 0.0.0.0 | | Indicators | LED indicator for each function | | Power Source | 12V DC, 2A (from power supply) or 12V DC over K−NET connection | | Dimensions (WxDxH) | 5.6 x 4.8 x 1.7" (14.3 x 12.2 x 4.4 cm) | | Weight | 1.4 lb (0.6 kg) | | | | Package Weight | 2.3 lb | | Box Dimensions (LxWxH) | 12.7 x 6.8 x 3.0" |
