Product description The Kramer Electronics TP-410 Distribution Amplifier is designed for computer graphics up to WUXGA or twisted pair video, unbalanced stereo or S/PDIF audio, and bi-directional RS−232 signals. The RS−232 signals and selected audio/video inputs are distributed to ten twisted pair outputs. - Resolution up to and including WUXGA (1920 x 1080)
- Selectable Inputs: Local or twisted pair (WUXGA, audio, and RS−232)
- Data handling extensive bi-directional RS−232 embedding, de−embedding and other options
- Selectable analog or digital audio input
- EDID Capture: Copies and stores the EDID from a display device.
- Transmission range up to 300' (100m) over STP cabling
- Flexible Control Options: Front panel, RS−232, RS−485, Ethernet
- Controls: Source selection buttons, power and source indicator LEDs, TP LEVEL, and EQ trimmers
- Worldwide Power Supply 100 to 240 VAC
In the Box Kramer TP-410 Distribution Amplifier Power Cord Windows Based Control Software Rack Ears Limited 7-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Kramer TP-410 Distribution Amplifier in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersKramer TP-410 Specs | Input | 1 x UXGA on a 15−pin HD connector 1 x Unbalanced Stereo Audio on a 3.5 mm Mini Jack 1 x S/PDIF on an RCA Connector 1 x Twisted Pair on an RJ−45 Connector | | Output | 10 x Twisted pairs on RJ−45 Connectors 1 x UXGA on 15−pin HD Connector 1 x Unbalanced Stereo Audio 3.5 mm Mini Jack 1 x S/PDIF on RCA Connector | | Control Ports | RS−232 3−pin terminal block (data and control), RS−485 3−pin terminal block (data and control), RJ−45 Ethernet (data and control). | | Resolution | Up to WUXGA (1920 x 1200) and 2k | | Maximum Output Level | Video: 1.6 Vpp
Audio: 2.3 Vpp | | Controls | RS−232/RS−485/Ethernet program control, source control from front panel, TP−IN level and equalization from rear panel | | Serial Baud Rate | Up to 19,200 b/s | | Serial Mode | Full-duplex | | Bandwidth | Audio: 20 Hz to 20 kHz @ 0.5 dB | | S/N Ratio | Audio: <−80dB | | Total Gain | Audio: 0 dB | | Coupling | Audio: AC | | THD + Noise | Audio: <0.03% | | Operating Temperature | 32 to 104°F (0 to 40°C) | | Storage Temperature | −40 to 158°F (−40 to 70°C) | | Humidity | 10 to 90%, RHL non−condensing | | Power Consumption | 100 to 240 VAC, 16 VA | | Rack Space | 1U rack unit | | Dimensions (WxD) | 19.00 x 7.52" (48.26 x 19.10 cm) | | Weight | 8.4 lb (3.8 kg) |
