Product description The Kramer Electronics TP-580T HDBaseT Twisted Pair Transmitter is a high−performance transmitter for HDMI, bidirectional RS-232, and IR signals. The TP-580T inputs HDMI, RS-232, and IR signals and converts them into an HDBaseT twisted pair signal that it transmits to a TP-580R receiver (sold separately). It supports transmission of 1080p, 2K, and 4K video signals over a distance of up to 230 feet. - Maximum data rate 10.2 Gb/s (3.4 Gb/s per graphic channel)
- HDMI supports deep color, x.v.Color, Lip Sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS−HD, and CEC
- EDID pass-through passes EDID signals between the source and display
- Transmits 1080p, 2K, and 4K video signals over a distance of up to 230' (70m)
- Bidirectional RS-232 & IR interface commands and data can flow in both directions via the RS−232 interface allowing status requests and remote control of the destination unit
- Cable for optimum range and performance use, use Kramer's BC−DGKat524, BC−DGKat623 and BC−DGKat7a23 cables (sold separately)
- Status LEDs for input, output, link, and power
- Compact DigiTOOLS 3 units can be rack mounted side−by−side in a 1U rack space with the RK−3T universal rack adapter (sold separately)
In the Box Kramer TP-580T HDBaseT Twisted Pair Transmitter Power Supply Limited 7-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Kramer TP-580T HDBaseT Twisted Pair Transmitter in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersKramer TP-580T Specs | Input | 1 HDMI connector | | Output | 1 HDBaseT twisted pair RJ−45 connector | | Ports | 1 IR on a 3.5 mm mini jack, 1 RS−232 on a 9−pin D−sub connector | | Transmission Range | 1080p, 2K, and 4K video at up to 230' (70 m) | | Bandwidth | 10.2 Gb/s (3.4 Gb/s per graphic channel) | | RS-232 | Baud Rate: 115200 | | Compliance With HDMI Standard | Supports HDMI and HDCP | | Power Consumption | 12 VDC, 275 mA | | Operating Temperature | 32 to 104°F (0 to 40°C) | | Storage Temperature | −40 to 158°F (−40 to 70°C) | | Humidity | 10 to 90%, RHL non−condensing | | Dimensions (W x D x H) | 7.4 x 4.5 x 1.0" (18.8 x 11.4 x 2.4 cm) | | Weight | 1.4 lb (0.6 kg) | | | | Package Weight | 1.2 lb | | Box Dimensions (LxWxH) | 8.9 x 4.8 x 3.4" |
