User Manual for Kramer TP-582R 1:2 Twisted Pair Receiver Click to enlarge the picture
Contents of the user manual for the Kramer TP-582R 1:2 Twisted Pair Receiver
- Product category: Video Extenders & Repeaters Kramer
- Brand: Kramer
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Kramer Video Extenders & Repeaters
 |
User manual for the Kramer TP-582R 1:2 Twisted Pair Receiver contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Kramer product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Kramer user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Kramer product will considerably shorten its lifespan!
|
Product description The Kramer TP-582R 1:2 Twisted Pair Receiver allows you to receive HDMI, Ethernet 100BaseT, RS-232 and IR input signals. It converts a twisted pair signal back to Ethernet 100BaseT, RS-232, IR and two HDMI outputs. Additionally, it also de-embeds audio to S/PDIF and TOSLINK audio outputs. The device offers a maximum data transfer rate of up to 2.25 Gbps over a distance of up to 330’ (100m). Shielded twisted pair (STP) cables such as Kramer's BC-DGKat524, BC-DGKat623, or BC-DGKat723 cables can be used for optimum performance.
The TP-582R 1:2 Twisted Pair Receiver supports HDMI v.1.4 with Deep Color, x.v.Color, Lip Sync, HDMI Uncompressed Audio Channels, Dolby TrueHD, DTS-HD, CEC, and 3D Pass-through. EDID PassThru feature helps in passing EDID/HDCP signals from the source to the display. The Ethernet interface uses 100BaseT connectivity, which features a high-data transfer rate for efficient transfer of data, video signals, etc.
A bidirectional RS-232 interface allows commands and data flow in both directions, thus allowing status requests and control of the destination unit. In addition, the device can be controlled via front panel buttons. An LED indicator displays input selection, output, link and power. Using an optional RK-T2B rack adaptor, you can mount 2 units side-by-side in a 1U rack space. Being HDCP compliant and HDTV compatible, the TP-582R 1:2 Twisted Pair Receiver is suitable for home theater, presentation, multimedia, and staging applications. Note: Transmission range depends on the signal resolution, graphics card and display used. The distance using non-Kramer CAT 5, CAT 6, and CAT 7 cables may not reach these ranges. Use only shielded cable where both ends of the shield are soldered to ground. - Allows you to receive HDMI, Ethernet 100BaseT, RS-232 and IR input signals
- Converts a twisted pair signal back to Ethernet 100BaseT, RS-232, IR and two HDMI outputs
- De-embeds audio to S/PDIF and TOSLINK audio outputs
- Maximum data transfer rate - up to 2.25 Gbps
- System range - up to 330' (100m)
- Supports HDMI v.1.4 with Deep Color, x.v.Color, Lip Sync, HDMI Uncompressed Audio Channels, Dolby TrueHD, DTS-HD, CEC, and 3D Pass-through
- EDID PassThru feature - helps in passing EDID/HDCP signals from source to display
- Ethernet interface - 100BaseT connectivity features a high data transfer rate for efficient transfer of data, video signals, etc
- LED indicator - displays input selection, output, link, and power
- Control via front panel buttons
- Bidirectional RS-232 Interface - allows commands and data flow in both directions, thus allowing status requests and control of the destination unit
- Compatible with shielded twisted pair (STP) cables such as Kramer's BC-DGKat524, BC-DGKat623, or BC-DGKat723 cables
- RK-T2B rack adaptor for mounting 2 units side side-by-side in a 1U rack space
- Suitable for home theater, presentation, multimedia, and staging applications
In the Box Kramer TP-582R 1:2 Twisted Pair Receiver TP-582R Twisted Pair Receiver 5V Power Cord RK-T2B Rack Adaptor User Manual 7-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Kramer TP-582R 1:2 Twisted Pair Receiver in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersKramer TP-582R Specs | Inputs | 1 RJ-45 connector | | Outputs | 2 HDMI connectors, 1 IR on a 3.5mm mini jack, 1 Ethernet 100BaseT on an RJ-45 connector, 1 RS-232 on a 9-pin D-sub connector, 1 TOSLINK® optical audio, 1S/PDIF in an RCA connector | | Bandwidth | Supports up to 2.25Gbps bandwidth per graphic channel | | Compliance With HDMI Standard | Supports HDMI and HDCP | | Power Source | 5V DC, 1.55A | | Dimensions (WxDxH) | 7.4 x 4.5 x 1.0" (18.8 x 11.4 x 2.4cm) | | Options | RK-T2B 19" rack mount | | Weight | 1.4 lb (0.6 kg) | | | | Box Dimensions (LxWxH) | 18.75 x 11.5 x 2.54" |
