User Manual for Kramer VA-8XL 8-Channel Balanced Stereo Volume Controller Click to enlarge the picture
Contents of the user manual for the Kramer VA-8XL 8-Channel Balanced Stereo Volume
- Product category: Distribution Amplifiers Kramer
- Brand: Kramer
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Kramer Distribution Amplifiers
|
User manual for the Kramer VA-8XL 8-Channel Balanced Stereo Volume contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Kramer product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Kramer user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Kramer product will considerably shorten its lifespan!
|
Product description The VA-8XL 8-Channel Balanced Stereo Volume Controller from Kramer is a high-performance 8-channel stereo input volume controller. It offers balanced audio signals on terminal block connectors by allowing the volume of each left and right channel to be adjusted independently of the other stereo channels. This unit is ideal for audio broadcasts, editing studios, PA remote audio level control, or any other difficult audio situation that requires the management of multiple feeds.
This unit features 8 x balanced stereo inputs and outputs. Large presentation audio controls facilitate management of this unit, as does the included Windows-based control software. This controller has been designed for international use and includes a worldwide power supply (100 to 240 VAC). It also features a standard 19" width and 1 RU height (1.8") to accommodate easy rack placement. - 8 x Audio Inputs & Outputs
- This solution offers 8 x balanced stereo audio inputs and outputs.
- Balanced Stereo Audio
- Balanced audio provides the highest quality signal possible.
- Control Software
- Manage your system with the included Windows-based software control package.
- Rack Ready
- This unit is designed to fit into a standard 19" rack and occupies only 1 RU (1.8") of rack space.
In the Box Kramer VA-8XL 8-Channel Balanced Stereo Volume Controller Power Cord Windows-Based Control Software Null Modem Adapter Limited 7-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Kramer VA-8XL 8-Channel Balanced Stereo Volume Controller in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersKramer VA-8XL Specs | Input | 8 x Balanced Stereo Audio + 4 dBm / 30 kOhms on Detachable Terminal Blocks | | Output | 8 x Balanced Stereo Audio + 4 dBm / 50 kOhms on Detachable Terminal Blocks | | Maximum Output Level | > 20 dBu Balanced (TND + N < 0.01) | | Bandwidth | 20 Hz to 40 kHz | | Gain | -95 dB to +31 dB | | Noise Floor | < 90 dB (Gain 0 dB) | | Control | Front Pushbuttons, RS-232, and RS-485 | | Total Harmonic Distortion (THD) + N | 0.006%, @ 4 dBm 1 kHz | | Signal to Noise Ratio | > 90 dB | | Indicators | Gain in dB for Left and Right Channels | | Power Source | 90 to 240 VAC, 13 VA | | Dimensions (W x D x H) | 19.0 x 7.2 x 1.8" / 48.3 x 18.3 x 4.4 cm | | Weight | 6.0 lb / 2.7 kg | | | | Package Weight | 8.3 lb | | Box Dimensions (LxWxH) | 21.4 x 10.9 x 4.3" |
