User Manual for Kramer VM-4HDXL 1:4 3G HD-SDI Video Distribution Amplifier Click to enlarge the picture
Contents of the user manual for the Kramer VM-4HDXL 1:4 3G HD-SDI Video
- Product category: Distribution Amplifiers (DA's) Kramer
- Brand: Kramer
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Kramer Distribution Amplifiers (DA's)
 |
User manual for the Kramer VM-4HDXL 1:4 3G HD-SDI Video contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Kramer product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Kramer user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Kramer product will considerably shorten its lifespan!
|
Product description The VM-4HDXL 1:4 3G HD-SDI Video Distribution Amplifier from Kramer is a distribution amplifier designed for use with SDI (SMPTE 259M and SMPTE 344M), HD-SDI (SMPTE 292M), and 3G HD-SDI (SMPTE 424M) signals. The unit accepts (1) input signal, reclocks and equalizes it, then redistributes it to (4) identical outputs. - It supports data rates up to 3Gbps
- Multi-standard operation includes support for SDI, HD-SDI, and 3G HD-SDI
- Kramer proprietary Reclocking & Equalization Technology rebuilds the digital signal to travel longer distances without signal loss
- LED lights provide a visual indication of line status
- This unit belongs to the Compact DigiTOOLS Series of products and up to (3) of these devices can be mounted side by side in 1U of rack space using the separately available RK-3T rack adapter
In the Box Kramer VM-4HDXL 1:4 3G HD-SDI Video Distribution Amplifier Power Supply Mounting Bracket Seven-Year Warranty Against Defects in Material & Workmanship User Manual PDF 1.1mbzvbcqrfadrvvf Table of Contents
|
Upload User Manual
Have you got an user manual for the Kramer VM-4HDXL 1:4 3G HD-SDI Video Distribution Amplifier in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersKramer VM-4HDXL Specs | Performance | Inputs:
(1) SMPTE-259M/292M/344M/424M serial video 75 Ohms on a BNC connector.
Outputs:
(4) equalized and reclocked SMPTE-259M/292M/344M/424M outputs 75 Ohms on BNC connectors
Maximum Data Rate:
2.97Gbps
Maximum Output Level:
800mVpp/75 Ohms
Coupling:
AC | | Power | 12VDC, 250mA | | Dimensions (HxWxD) | 0.95 x 4.73 x 2.79" (2.42 x 12.02 x 7.08cm) | | Weight | 0.31 lbs (0.3kg) | | | | Package Weight | 1.2 lb | | Box Dimensions (LxWxH) | 9.0 x 4.8 x 3.4" |
