Product description The KVM-TEC MVX2-F Masterline Dual Fiber Receiver pairs with an optional transmitter and extends DVI and USB signals up to 1640' over two duplex multimode LC fiber cables, sold separately. It accepts 1920 x 1200 at 60 Hz resolution video with less than 5ms latency and 1080p signals in real time.
Two DVI ports output two monitor signals and four USB ports allow you to output keyboard, mouse, and USB hard drive and memory stick signals. (The receiver and corresponding transmitter must both be upgraded to support hard drive capture. Additionally, the included SFP modules can be replaced on both ends with separately sold single-mode modules to allow a transmission distance of up to 99 miles. Please see the Accessories tab for all compatible software/hardware upgrade options.) 3.5mm line in and line out jacks are provided for local speaker and mic connectivity.
The USB ports are USB 2.0 transparent, meaning they're backwards-compatible with USB 1.0 and also support USB 3.0 but at USB 2.0 speeds. Up to 48 transmitter and receiver units can be integrated into a single workflow by connecting them to an optional network switch. Any standard KVM-TEC or third-party switch is supported. Up to two units can be installed in a 19" rack using optional rackmount kits.
- Key Features
-
- Accepts DVI and USB signals up to 1640' over two duplex multimode LC fiber cables, sold separately (optional single-mode modules are supported for longer distances)
- Supports 1920 x 1200 at 60 Hz with less than 5ms latency, 1080p in real time
- Two DVI ports output two monitor signals
- Four USB 2.0 ports support keyboard, mouse, and USB hard drives and memory sticks (the receiver and corresponding transmitter must be upgraded to support hard drive/memory stick capture)
- USB 2.0 ports are backwards-compatible with USB 1.0 and also support USB 3.0 at USB 2.0 speeds
- Up to 480 Mb/s USB transmission rate
- 3.5mm audio line in and line out jacks
- Automatic plug-and-play operation
- Free-air convection cooling
- Can be integrated into a 48-endpoint workflow via any standard network switch
- Rackmountable via optional rackmount kits
- MTBF: 82.820 calculated hours over approximately 10 years
In the Box KVM-TEC MVX2-F Masterline Dual Fiber Receiver Power Supply (12 VDC, 2 A) 2 x SFP Multimode Modules 4 x Rubber Feet 4 x Mounting Pads Limited 2-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the KVM-TEC MVX2-F Masterline Dual Fiber Receiver in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersKVM-TEC Masterline MVX2-FR Specs | | | Ports | Receiver:
2 x DVI (Output)
4 x USB Type-A USB 2.0
1 x 3.5 mm Audio (Input)
1 x 3.5 mm Audio (Output)
2 x LC Fiber (Input) | | Supported Resolutions | 1920 x 1200 @ 60 Hz
1920 x 1080 | | Maximum Transmission Distance | 1640' / 499.87 m | | Transmission Method | Multimode Cable | | Color Depth | 24-Bit | | Audio Channels Supported | 2-Channel Stereo (16-Bit) | | | | DC Input Power | 12 VDC at 2 A | | Power Consumption | 12 W Without USB Devices | | | | Operating Temperature | 32 to 113°F / 0 to 45°C | | Storage Temperature | -13 to 176°F / -25 to 80°C | | Operating Humidity | 80% | | | | Certifications | CE, FCC, as per Manufacturer | | Material of Construction | Aluminum | | Dimensions | 7.8 x 1.6 x 4.1" / 19.8 x 4.1 x 10.4 cm | | Weight | 1.3 lb / 582.0 g |
