Product description The KVM-TEC MX 2000 Matrixline IP Transmitter pairs with an optional receiver and extends DVI and USB signals up to 492' over a single CAT5e/6/7 cable, sold separately. It transmits 1920 x 1200 at 60 Hz resolution video with less than 5ms latency and 1080p signals in real time. A single USB connection captures keyboard and mouse signals as well as USB hard drives and memory sticks thanks to a built-in USB upgrade feature.
An RS-232 port, DVI monitoring output, and 3.5mm line in and line out jacks are provided, and the device can be integrated into a workflow of up to 2000 transmitter/receiver units via connection to an optional network switch. Any standard KVM-TEC or third-party switch is supported. Up to four units can be installed in a 19" rack using optional rackmount kits. The USB port is USB 2.0 transparent, meaning it's backwards-compatible with USB 1.0 and also supports USB 3.0 but at USB 2.0 speeds. - Key Features
-
- Transmits DVI signal and USB keyboard, mouse, hard drive, and memory stick signals up to 492' over a single CAT5e/6/7 cable, sold separately
- 1920 x 1200 at 60 Hz transmission with less than 5ms latency, 1080p transmission in real time
- RS-232 port
- Can be integrated into 2000-endpoint workflows via any standard network switch
- USB 2.0 port is backwards-compatible with USB 1.0 and also supports USB 3.0 at USB 2.0 speeds
- Up to 480 Mb/s USB transmission rate
- 3.5mm audio line in and line out jacks
- DVI local monitoring output
- Automatic plug-and-play operation
- Free air convection cooling
- Four units are rackmountable via optional rackmount kits
- MTBF: 82.820 calculated hours over approximately 10 years
In the Box KVM-TEC MX 2000 Matrixline IP Transmitter Power Supply (12 VDC, 1 A) DVI to DVI Cable (6') USB Cable (6') VGA to DVI Cable (6') 2 x Audio Cables (6') RJ11 to D9 Adapter for RS-232 RS-232 Extension Cable (6') 4 x Rubber Feet 4 x Mounting Pads Limited 2-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the KVM-TEC MX 2000 Matrixline IP Transmitter in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersKVM-TEC 6711L Specs | | | Ports | Transmitter:
1 x DVI (Input)
1 x DVI (Output)
1 x USB Type-B USB 2.0
1 x 3.5 mm Audio (Input)
1 x 3.5 mm Audio (Output)
1 x RJ11 RS232
1 x RJ45 (Output) | | Supported Resolutions | 1920 x 1200 @ 60 Hz
1920 x 1080 | | Maximum Transmission Distance | 492' / 149.96 m | | Transmission Method | CAT5e/CAT6/CAT7 Cable | | Color Depth | 24-Bit | | Audio Channels Supported | 2-Channel Stereo (16-Bit) | | RS232 Data Rate | 230,400 bps | | | | DC Input Power | 12 VDC at 1 A | | Power Consumption | 6 W | | | | Operating Temperature | 32 to 113°F / 0 to 45°C | | Storage Temperature | -13 to 176°F / -25 to 80°C | | Operating Humidity | 80% | | | | Certifications | CE, FCC, as per Manufacturer | | Material of Construction | Aluminum | | Dimensions | 3.8 x 1.6 x 4.1" / 9.7 x 4.1 x 10.4 cm | | Weight | 0.7 lb / 302.0 g |
