Product description Provided by third party: As 12G / 4K UHD continues to shape the landscape of broadcast TV, sports, live events and commercial production workflows, Laird delivers the most advanced BNC cables on the market for effectively transmitting 12G-SDI signals up to 325 feet. Utilizing Canare L-5.5CUHD coaxial, these BNC cables are the right choice to future-proof facility installs in studios and broadcast towers as well as outside broadcast interface applications.
This coax cable has enhanced attenuation characteristics that allow transport of 12G signals at much greater distances than comparable-sized coax. Cables are fully SMPTE ST-2082-1 compliant and hand crafted with Canare L-5.5CUHD miniature coaxial and BCP-D55UHD connectors. A superb return loss at 12 GHz of 15 dB, 20 dB @ 6 GHz & 26 dB @ 3 GHz makes these cables perfect for 12G, 6G and 3G systems.
- Key Features
-
- Designed for UHD and 4K video transport
- SDI formats including 1.5G, 3G, 6G and 12G SDI SMPTE 2082-1 standards
- Fixed and cable reel deployment in studios, trucks, permanent installations
- Excellent attenuation
- Terminated with 12G 75O BNC connectors
- Flamed retardant
Table of Contents
|
Upload User Manual
Have you got an user manual for the Laird Digital Cinema BNC to BNC 12G-SDI 4K UHD Video Coaxial Cable in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersLaird Digital Cinema 12GSDI-B-B-125 Specs | | | Cable Type | Video cable - 4K support | | Interface Supported | 12G-SDI | | Technology | Coaxial | | Impedance | 75 Ohm | | Length | 125 ft | | Features | Foam Polyethlene (FPE) insulation, flame retardant, copper conductors | | | | CONNECTOR | BNC - male | | Connector (Second End) | BNC - male |
