Product description The HD LAN IPTV/ASI IP Interface from Leader adds an IP to ASI/de-encapsulator to your HD TAB 9 touchscreen analyzer. It encaps/de-encaps IP signals to ASI and ASI signals to IP. It also provides you with T.S. live streaming/recording, remote PC/Tabler control, and SNMP & HTTP. In the Box Leader HD LAN IPTV/ASI IP Interface for HD TAB 9 Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Leader HD LAN IPTV ASI IP Interface for HD TAB 9 in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersLeader HD LAN IPTV/ASI Specs | LAN | 1 Gb/s Ethernet interface | | Protocol | UNICAST/MULTICAST RTP/UDP WITH 2 dimensional FEC IGMP v2 | | Forward Error Correction | Pro MPEG CoP# / SMPTE 2022
Status: No FEC, FEC1, FEC2 | | Streaming | Status: Present, Not Present | | Packet Size | MPEG: 1 - 7 | | Ethernet Port | Input: 1, 2, both | | Bitrate | TS: 0 - 216 Mb/s | | Packets | Successfully recovered: 0 - ∞
Missing: 0 - ∞
L: 1 ≤ L ≤ 20
D: 4 ≤ D ≤ 20 | | Jitter | IP Stream: 0 - 1000 ms | | IP Access Trunk | MIN, MAX, MED, Jitter | | ASI | Mode: MPEG-TS on ASI Compliant to EN 50083-9 packet length 188/204 bytes
Status: Lock 188, Lock 204, Unlock
Bitrate: 0 - 216 Mb/s | | MAC Address | Destination: Unicast- MAC is the host receiver
Multicast- MAC multicast defined by the destination IP address | | Content | Transport stream: MPEG2 and MPEG4 HD Service |
