Product description How to Use ND Filters: Tips, Tricks, and Special Effects Read More - Introduction to LEE Filters
- Product Demo
The 100 x 150mm Combination 81EF and 0.3 Soft-Edge Graduated Neutral Density Filter from LEE Filters is compatible with a LEE Filters 100mm System filter holder. This filter can be applied to create a warm cast over an entire image while darkening specific areas of that image, such as bright skies. This combination effect can be obtained under daylight when this filter is used on a film camera system with daylight film installed, or on a digital camera system with its daylight white balance setting selected. This filter's overall coloration corresponds to an ability to reduce 3850K color temperatures to 3200K, which reflects a mired shift value of +53 that can be applied to other starting color temperatures as well. While the ability to generate a warm cast extends throughout the entire filter, its neutral density feature is most pronounced at the edge and tapers to clear by the middle, with a soft-edged line of transition between the areas with and without its neutral density coloration.
This filter is non-coated and is constructed from optical-quality resin for clarity as well as color fidelity. Where its neutral density coloration is most pronounced, the LEE Filters 100 x 150mm Combination 81EF and 0.3 Soft-Edge Graduated Neutral Density Filter has a 0.5 density with a 3x filter factor that darkens the corresponding area of an image by 1.6 stops. This is due in part to the 0.2 density of the filter's overall warm cast.
The greater the color temperatures they can potentially reduce to 3200K, light balancing filters are considered to be progressively stronger in their effect when used to add warmth to a daylight image. -
- Can add a warming cast to an entire image under daylight when used on a film camera system with daylight film installed, or on a digital camera system with its daylight white balance setting selected
- Provides a mired shift value of +53
- Reduces 3850K color temperature to 3200K
- Darkens bright areas of an image, such as skies
- Provides up to a 1.6-stop reduction of light in selective areas
- Provides at least a 0.6-stop reduction of light
- Constructed from optical-quality resin for clarity
- Padded filter pouch included for storage and transport
UPC: 619465018248 In the Box LEE Filters 100 x 150mm Combination 81EF and 0.3 Soft-Edge Graduated Neutral Density Filter Filter Pouch Limited Lifetime Warranty Introduction to ND Filters: The Basics BH Online Videos 05/29/2015 cbxzbzdqsq How to Use ND Filters: Beyond the Basics BH Online Videos 05/29/2015 Table of Contents
|
Upload User Manual
Have you got an user manual for the LEE Filters 100 x 150mm Combination 81EF and 0.3 Soft-Edge Graduated Neutral Density Filter in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersLEE Filters 81EFWN3S Specs | Filter Type | Graduated ND Combination | | Combination Type | 81EF Color Conversion | | Graduation Type | Soft Edge | | Graduation Direction | Vertical | | Density | 0.5 (1.6 Stops) | | Shape | Rectangle | | Rectangular Size | 3.9 x 5.9" / 100.0 x 150.0 mm | | Filter Thickness | 0.08" / 2 mm | | Filter Material | Resin | | | | Package Weight | 0.2 lb | | Box Dimensions (LxWxH) | 7.3 x 5.4 x 0.5" |
