Product description - Introduction to LEE Filters
Lee 4x4" CC20C (Cyan) Color Compensating (Color Correction) filters act specifically on relatively narrow bands of color. That is why they do not come in two color variants (bluish and reddish) like conversion filters do. Instead, they come in three primary additive colors and their three secondary colors (which can be interpreted as the primary colors of subtractive mixing) - each color comes in practical density steps. Lee color compensating filters are made in the following increasing densities: 0.025(CC025), 0.05(CC05), 0.10(CC10), 0.15(CC15), 0.20(CC20), 0.25(CC25), 0.30(CC30), 0.40(CC40), 0.50(CC50). You can sandwich as many as three Lee polyester filters together without a noticeable loss of image quality. Some photographic situations require specific color corrections. For example, when shooting daylight film under fluorescent lighting, some magenta correction is needed in order to remove the greenish tint that would otherwise appear. The amount of color correction required is most accurately measured via a color temperature meter. Note: Lee polyester filters are made from lightweight, optical polymeric materials and are available in 3 x 3" (75 x 75 mm) and 4 x 4" (100 x 100 mm) - Color Compensating filters are made of gelatin and are available in the three primary colors: Red, Green, and Blue; and in the three secondary colors: Cyan, Magenta, and Yellow
- A typical designation for one of these filters is CC30M; The "CC" stands for Color Compensating; The "30" stands for a density of 0.30 and the "M" is for magenta
Color Compensation Filter Factors - CC05B: in Daylight = 1.2: in Tungsten = 1.2
- CC10B: in Daylight = 1.3: in Tungsten = 1.3
- CC20B: in Daylight = 1.6: in Tungsten = 1.6
- CC40B: in Daylight = 2.1: in Tungsten = 2.4
- CC05Y: in Daylight = 1.1: in Tungsten = 1.1
- CC10Y: in Daylight = 1.1: in Tungsten = 1.2
- CC20Y: in Daylight = 1.2: in Tungsten = 1.2
- CC40Y: in Daylight = 1.4: in Tungsten = 1.3
- CC05C: in Daylight = 1.1: in Tungsten = 1.1
- CC10C: in Daylight = 1.1: in Tungsten = 1.2
- CC20C: in Daylight = 1.3: in Tungsten = 1.4
- CC40C: in Daylight = 1.4: in Tungsten = 1.5
- CC05R: in Daylight = 1.2: in Tungsten = 1.1
- CC10R: in Daylight = 1.3: in Tungsten = 1.2
- CC20R: in Daylight = 1.5: in Tungsten = 1.4
- CC40R: in Daylight = 2.1: in Tungsten = 1.9
- CC05G: in Daylight = 1.1: in Tungsten = 1.1
- CC10G: in Daylight = 1.2: in Tungsten = 1.2
- CC20G: in Daylight = 1.3: in Tungsten = 1.3
- CC40G: in Daylight = 1.5: in Tungsten = 1.5
- CC05M: in Daylight = 1.2: in Tungsten = 1.1
- CC10M: in Daylight = 1.3: in Tungsten = 1.2
- CC20M: in Daylight = 1.5: in Tungsten = 1.3
- CC40M: in Daylight = 1.9: in Tungsten = 1.5
UPC: 619465003244 Table of Contents
|
Upload User Manual
Have you got an user manual for the LEE Filters 4x4" CC20C Color Compensating Polyester Filter in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersLEE Filters SKA-C25-V1 Specs | Type | Color Compensating | | Size | 4x4" (100 x 100 x 2 mm) | | Grade | CC20C (Cyan) | | Filter Factor | CC20C: in Daylight = 1.3: in Tungsten = 1.4 | | Multi-Coated | No | | Rotating | No | | Effect | Helps with color balance when shooting with any lighting source | | Application | Architectural, portrait, product photography | | Color Temperature | Not specified | | Construction | Polyester | | Front Filter Thread Size | Not applicable | | Front Lens Cap Size | Not applicable | | | | Package Weight | 0.04 lb | | Box Dimensions (LxWxH) | 4.25 x 4.2 x 0.05" |
