User Manual for Letus35 MCS ActionCam Bundle for Nikon D800 With Basic Matte Box Click to enlarge the picture
Contents of the user manual for the Letus35 MCS ActionCam Bundle for Nikon
- Product category: DSLR Video Supports & Rigs Letus35
- Brand: Letus35
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Letus35 DSLR Video Supports & Rigs
|
User manual for the Letus35 MCS ActionCam Bundle for Nikon contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Letus35 product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Letus35 user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Letus35 product will considerably shorten its lifespan!
|
Product description The Letus35 MCS ActionCam Bundle for Nikon D800 With Basic Matte Box is a minimal, lightweight camera rig providing you with high functionality and ease of movement. This camera rig was designed to be as compact and nimble as possible for use in tight spaces and for action photography. The camera interface plate attaches to the bottom of the camera and is the mounting platform for attaching your camera to the quick release base of the cage. Included with the Action Cam bundle is the short plate, which is designed to only extend the length of the cage and does not provide support for a rear stabilizer. It is also machined from high-grade aluminum and anodized for additional strength. The included Letus Basic Matte Box includes the matte box and a 15mm rod clamp--the matte box can hold two 4x5.65 filters at an angle or three 4x5.65 filters straight. A rail mount is also included for mounting the matte box to 15mm support rods (not included). It also has a marking window to mark polarizer positions for easy repeatability. The matte box is made from CNC-machined high-grade aluminum and extremely durable polymers. The camera cage, to which everything else is attached, is CNC-milled aluminum and hard anodized for durability. The cage design incorporates numerous 1/4-20" and 3/8-16" sockets around the entire cage for a large variety of accessory mounting options. Other accessories included with the bundle are a dovetail, a quick release clamp, a clamp-to-rod adapter, a handle, and a pair of 6" (15.4 cm) black rods. These pieces work together in establishing a strong camera rig system that provides a multitude of mounting options for accessories and other tools. - Camera Interface Plate
- The camera interface plate attaches to the bottom of the camera and is the mounting platform for attaching your camera to the quick release base of the cage. Included with the Action Cam bundle is the short plate, which is designed to only extend the length of the cage and does not provide support for a rear stabilizer. It is also machined from high grade aluminum and anodized for additional strength.
- Nikon D800 Non-Powered Cage
- The cage is built from CNC-milled high-grade aluminum that is hard anodized for further durability. Featuring numerous 1/4-20" and 3/8-16" sockets, this cage permits mounting a large variety of accessories to the cage as well as being able to easily mount the cage to other platforms. It is highly durable and lightweight, weighing just over a pound; this cage is easy to maneuver and provides protection to your camera body.
- Dovetail
- The dovetail is typically mounted to the camera cage and provides flexible positioning for the quick release clamp. Outfitted with 1/4-20" mounting holes along the border of the dovetail, it can be mounted and easily aligned on a variety of bases.
- 6" Rods
- These 6" black rods are an industry-standard 15mm in diameter and provide mounting accessibility for a follow focus and other accessories. They are made from hard-anodized aluminum for durability and smoothness of use.
- Quick Release Clamp
- Designed to work quickly and efficiently with the dovetail, the quick release clamp allows for system modifications on the fly. It is perfect for mounting accessories such as an extra handle or a remote for a follow focus above the lens and having them be easily accessible. The design also integrates a blind attachment system, allowing you to simply push the quick release onto the dovetail for connection instead of having to use two hands or precisely line it up for proper attachment.
- Clamp to Rod Adapter
- This adapter works in conjunction with the quick release clamp and provides simple attachment of two standard 15mm rods to the top clamp. The rods are necessary for use with iris rods and a remote follow focus. This adapter brings flexibility to where you can mount your accessories by making use of the quick release and dovetail.
- Top Handle
- This handle provides a versatile grip point that can be mounted to the standard 15mm rods for a large variety of placement options. Featuring a stainless steel rosette pivot plate, the handle can be rotated and locked in 30° increments. It is CNC-milled from high-grade billet aluminum and features a silicon grip for extra comfort and durability.
In the Box Letus35 MCS ActionCam Bundle for Nikon D800 With Basic Matte Box Camera Interface Plate (Short) Nikon D800 Non-Powered Cage Basic Matte Box Dovetail Quick Release Clamp Clamp-to-Rod Adapter 6" Black Rods Top Handle 1-Year Limited Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Letus35 MCS ActionCam Bundle for Nikon D800 With Basic Matte Box in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersLetus35 Action Cam Specs | | | Cage | 6.75 x 5.5 x 3.25" / 17.2 x 14 x 8.3 cm
1.3 lb / 0.6 kg | | Camera Interface Plate | 2.75 x 3.1 x 0.6" / 7 x 7.9 x 1.5 cm
5.6 oz / 158.8 g | | Dovetail Plate | 5.5 x 1.5 x 0.4" / 14 x 3.8 x 1 cm
3.2 oz / 90.7 g | | Quick Release Plate | 3.1 x 0.75 x 3" / 7.9 x 1.9 x 7.6 cm
7.2 oz / 204.1 g | | Iris Rods | 0.5 x 6 x 0.5" / 1.3 x 15.4 x 1.3 cm
4 oz / 113.4 g | | Handle | 1.25 x 8.5 x 3.75" / 3.2 x 21.6 x 9.5 cm
9.6 oz / 272.2 g | | Entire Rig (Assembled) | 7.75 x 6.75 x 10.5" / 19.7 x 17.2 x 26.7 cm
3.4 lb / 1.5 kg | | | | Package Weight | 5.0 lb | | Box Dimensions (LxWxH) | 9.0 x 9.0 x 9.0" |
