User Manual for Leupold 6-18x40 Mark AR MOD 1 Riflescope Click to enlarge the picture
Contents of the user manual for the Leupold 6-18x40 Mark AR MOD 1
- Product category: Riflescopes Leupold
- Brand: Leupold
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Leupold Riflescopes
|
User manual for the Leupold 6-18x40 Mark AR MOD 1 contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Leupold product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Leupold user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Leupold product will considerably shorten its lifespan!
|
Product description Leupold's 6-18x40 Mark AR MOD 1 Riflescope provides you with medium-to-long range shooting capabilities and features a Mil Dot Reticle that is coated with Leupold's proprietary index-matched coatings to maximize transmission of light, and blackened lens edges to reduce glare. Another highlight of the optical system is the protective DiamondCoat lens coating, which uses an ion-assisted process to harden the surface of the objective lens for resistance against debris and abrasions. To help you compensate for wind drift and ballistic drops, the scope offers 1/10 mil impact point correction and 22 MRAD windage and elevation adjustment ranges. The Mil-Dot Reticle is defined by four bold posts and a crosshair with evenly spaced beads.
Decorated with a 24kt gold-plated ring and a medallion, the aluminum housing is lightweight, durable, waterproof, and fogproof. It offers a 1" maintube, a lockable eyepiece with a low-profile lever for fast zooming action, and an exposed, finger-operated P5 elevation turret for .223 rounds. - Optical Performance
-
- 40mm objective lens
- Index-matched anti-reflection lens coatings
- Blackened optical elements' edges reduce straight light and glare
- DiamondCoat lens coating:
- Ion-assisted process hardens lens surface
- Provides resistance against debris and abrasions
- Mil Dot Reticle
-
- Four bold posts
- Crosshair with evenly spaced beads
- Use and Handling
-
- 1/10 mil impact point correction
- 22 MRAD windage and elevation ranges
- Construction Details
-
- Single-piece maintube
- Aluminum housing
- Finger-operated tactical turrets
- Exposed, tactical P5 elevation turret for .223 rounds
- Lockable eyepiece with a low-profile zoom lever
- Adjustable objective parallax corrector
- Single bias spring, 3x erector
- 2nd Gen argon/krypton fog proofing
- Waterproof and impact-resistant
UPC: 030317153946 In the Box Leupold 6-18x40 Mark AR MOD 1 Riflescope (Mil Dot Reticle, Matte Black) - Limited Lifetime Warranty
Table of Contents
|
Upload User Manual
Have you got an user manual for the Leupold 6-18x40 Mark AR MOD 1 Riflescope in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersLeupold 115394 Specs | | | Magnification | 6 to 18x | | Objective Lens Diameter | 40 mm | | Field of View | 6x: 15.2' @ 100 yd / 5.1 m @ 100 m
18x: 6.7' @ 100 yd / 2.2 m @ 100 m | | Exit Pupil Diameter | 6x: 6.2 mm
18x: 2.3 mm | | Eye Relief | 3.7 to 4.9" / 94 to 124.5 mm | | | | Reticle Type | MIL Dot Reticle | | | | Impact Point Correction | 1/10 MRAD per Click | | Windage Adjustment | 75 MOA | | Elevation Adjustment | 22 MRAD | | | | Water Resistance | Waterproof | | Fogproof | Yes | | | | Maintube Diameter | 1" | | Battery | None | | Dimensions | Length: 13.5" / 342.9 mm | | Weight | 15.3 oz / 433 g | | | | Package Weight | 1.7 lb | | Box Dimensions (LxWxH) | 17.0 x 4.1 x 3.4" |
