Product description Levenhuk's 850B Binocular Microscope is a lab-grade microscope that is equipped with a Siedentopf interpupillary adjustment (55-75mm), four plan achromatic objectives, and two pairs of eyepieces (10x and 20x), which together can produce high-resolution images with low color distortions at magnifications of up to 2000x. For improved image clarity, detail, and brightness, the optics are made of achromatic glass. Additionally, plan (planar) achromatic objectives offer better correction for color distortions and geometric distortions, as well as provide field flatness for 95% of the field of view. Users should take note that its 100xs objective ought to be used with a special immersion oil (included) to achieve maximum resolution and to prevent driving the objective into your slide. To augment the optical performance, the scope offers matching mechanical features as well. Its large (6.1 x 5.5") square specimen stage provides full motion control in two dimensions via Vernier adjustments, and a lockable slide bracket. You can obtain bright and high-contrast images using its bottom 20W halogen lamp illumination system, a 1.25 NA Abbe condenser, and a built-in iris diaphragm. For obtaining precise image sharpness, the scope provides both coarse and fine focusing, adjustable using the coaxial knurled knobs with precision graduations. - Optical Performance
-
- Achromatic glass optics
- Plan 4x, 10x, 40xs, and 100xs objectives
- 100xs objective ought to be used with the included immersion oil
- 40xs and 100xs have spring mechanisms
- 10x and 20x widefield eyepieces
- 40-2000x magnification range
- 1.25 NA Abbe condenser
- Use and Handling
-
- 30°-inclined binocular viewing
- Siedentopf interpupillary adjustment: 55 - 75mm
- External 110V outlet required
- 20W halogen lamp with adjustable brightness
- Built-in iris diaphragm and filter wheel
- Blue, yellow, and green filters included
- +5 to -5 diopter adjustment
- Stage
-
- 6.1 x 5.5" mechanical precision stage
- Vernier motion controls for both axes
- Lockable specimen bracket
- Construction Details
-
- Metal frame
- Arched back serves as a handle
- Wide base provides stability
- Knurled focusing knobs
In the Box Levenhuk 850B Binocular Microscope (110V, Matte Black) - 2 x 20x WF Eyepieces
- Immersion Oil
- 3 x Filters
- Mirror
- 110V Power Cable
- Limited Lifetime Warranty
Table of Contents
|
Upload User Manual
Have you got an user manual for the Levenhuk 850B Binocular Microscope in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersLevenhuk 850B Specs | Microscope Type | Compound | | Eyepiece | 10x WF, 20x WF | | Nosepiece | Rotating ball-bearing | | Objectives | 4x Plan: 0.1 NA, 1.45" (37.0 mm) working distance
10x Plan: 0.25 NA, 0.28" (7.1 mm) working distance
40xs Plan: 0.65 NA, 0.025" (0.63 mm) working distance
100xs Plan: 1.25 NA, 0.006" (0.158 mm) working distance | | Head | Siedentopf Interpupillary Adjustment: 55 - 75 mm | | Viewing | 30°-inclined binocular | | Focuser | Coaxial fine and coarse
Coarse Focus Range: 25 mm
Fine Focus / Accuracy: 2 µm | | Diopter Adjustment | +5 to -5 | | Light Source | 6 V, 20 W halogen lamp | | Light Control | Rheostat | | Specimen Stage | Two-axis precision stage
Dimensions: 6.1 x 5.5" / 155 x 140 mm
Range of Motion: 2.8 x 2.0" / 70.0 x 50.0 mm
Iris Diaphragm Range: 0.1 - 1.2" / 2.0 - 30.0 mm | | Environmental Conditions | Operating Temperature: 32 - 104°F / 0 to 40°C
Maximum Humidity: 85% | | Overall Dimensions | Not provided by manufacturer | | Weight | Not provided by manufacturer |
