User Manual for LG 24M47VQ-P 24" 16:9 LCD Monitor Click to enlarge the picture
Contents of the user manual for the LG 24M47VQ-P 24" 16:9 LCD Monitor
- Product category: Computer Monitors LG
- Brand: LG
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for LG Computer Monitors
 |
User manual for the LG 24M47VQ-P 24" 16:9 LCD Monitor contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any LG product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official LG user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a LG product will considerably shorten its lifespan!
|
Product description 10 Factors to Consider When Selecting A Monitor for Video Editing Read More The 24M47VQ-P 24" 16:9 LCD Monitor from LG features a 16:9 aspect ratio allowing you to divide the display into four separate sections, eliminating the need to flip between documents. The monitor supports Full HD 1920 x 1080p resolution, and the 2 ms response time allows better clarity and vivid quality when viewing action scenes, sports, and video games. Its dimming technology is applied to minimize the flicker level that may cause eye fatigue. With almost-zero flicker technology, looking at your computer screen for longer periods of time is more comfortable. - 2 ms Response Time
- The 2 ms response time allows smooth viewing of action scenes, sports, and video games with better clarity and vivid quality. The consistent response time also allows you to watch videos or play games for a longer time while minimizing eyestrain.
- 4-Screen Split
- The 4-screen split feature eliminates shuffling back and forth between windows. With a single click feature, the monitor divides the screen into as many as four customizable segments, so you can see four different windows at the same time.
- Reader Mode
- Reducing blue light to help lessen eye fatigue, Reader mode provides optimal condition for reading. With just a touch of a button, you can more comfortably read your monitor screen.
- Flicker Safe
- The dimming technology is applied to minimize the flicker level that may cause eye fatigue. With almost-zero flicker technology, looking at your computer screen for longer periods of time is more comfortable.
- ENERGY STAR Qualified
- The monitor meets strict energy efficiency guidelines set by the US Environmental Protection Agency and the Department of Energy. It means it saves energy both in standby and active (powered on) modes. ENERGY STAR-qualified monitors use about 25% less energy than standard units.
UPC: 719192195721 In the Box LG 24M47VQ-P 24" 16:9 LCD Monitor VGA Cable Owner's Manual CD Power Cord AC-DC Adapter Stand Body Stand Base Limited 3-Year Warranty User Manual PDF 7.3mb Table of Contents
|
Upload User Manual
Have you got an user manual for the LG 24M47VQ-P 24" 16:9 LCD Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersLG 24M47VQ-P Specs | | | Size | 23.6" | | Touchscreen | No | | Resolution | 1920 x 1080 | | Aspect Ratio | 16:9 | | Maximum Brightness | 250 cd/m2 | | Dynamic Contrast Ratio | 5,000,000:1 | | Refresh Rate | 60 Hz | | Adaptive Sync Technology | None | | Horizontal Frequency | 30 to 83 kHz | | Vertical Frequency | 56 to 61 Hz | | Color Gamut | 72% sRGB | | Response Time | 2 ms (GtG) | | Dot Pitch | 0.272 x 0.272 mm | | | | Connectivity | 1 x HDMI
1 x VGA | | | | Power Consumption | 22 W (Typical)
0.3 W (Standby) | | DC Input Power | 19 VDC at 1.2 A | | | | Operating Temperature | 50 to 95°F / 10 to 35°C | | Storage Temperature | -4 to 140°F / -20 to 60°C | | Operating Humidity | 10 to 80% | | Storage Humidity | 5 to 90% | | | | Tilt Adjustment | -5 to 20° | | Dimensions (W x H x D) | 21.9 x 13.6 x 2.6" / 55.7 x 34.2 x 6.8 mm (Without Stand)
21.9 x 17.2 x 7.7" / 55.7 x 43.8 x 19.7 mm (With Stand) | | Weight | 6.1 lb / 2.8 kg | | | | Package Weight | 8.8 lb | | Box Dimensions (LxWxH) | 24.0 x 16.0 x 5.0" |
