User Manual for LG 24MB65PY-I 24" 16:10 IPS LCD Monitor Click to enlarge the picture
Contents of the user manual for the LG 24MB65PY-I 24" 16:10 IPS LCD
- Product category: Computer Monitors LG
- Brand: LG
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for LG Computer Monitors
 |
User manual for the LG 24MB65PY-I 24" 16:10 IPS LCD contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any LG product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official LG user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a LG product will considerably shorten its lifespan!
|
Product description 10 Factors to Consider When Selecting A Monitor for Video Editing Read More The 24MB65PY-I 24" 16:10 IPS LCD Monitor from LG offers viewing angles of 178°/178° and a brightness rating of 300 cd/m2. This unit has a native resolution of 1920 x 1200. The contrast ratio of 1000:1 showcases the monitor's ability to handle light and dark images on-screen. The panel has a 5 ms response time to combat image blur and distortion on moving images. -
- Picture mode
- Reader mode
- DDC/CI
- HDCP
- Intelligent auto adjustment
- key lock
- Plug-and-play
- Response time
- Color calibrated
- Control keys (MENU, MY KEY, FUNC, AUTO, INPUT, and POWER)
- LED Color: White (On mode), White blinking (Power save mode)
- Anti-glare, 3H surface treatment
- Six-axis control
- Flicker safe
- Detachable base
- Mini PC bracket ready
UPC: 719192613959 In the Box LG 24MB65PY-I 24" 16:10 IPS LCD Monitor DVI-D Cable DisplayPort Cable USB Cable PC Audio Cable Power Cable Limited 3-Year Warranty User Manual PDF 9.7mbctyusdyvtxedatfffcayfzw More from Manufacturer Table of Contents
|
Upload User Manual
Have you got an user manual for the LG 24MB65PY-I 24" 16:10 IPS LCD Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersLG 24MB65PY-I Specs | | | Size | 24" | | Panel Type | IPS-Type LCD | | Touchscreen | No | | Resolution | 1920 x 1200 | | Aspect Ratio | 16:10 | | Pixels Per Inch (ppi) | 94 ppi | | Finish | Matte | | Hardness Rating | 3H | | Maximum Brightness | 300 cd/m2 | | Contrast Ratio | 1000:1 | | Dynamic Contrast Ratio | 5,000,000:1 | | Adaptive Sync Technology | None | | Horizontal Frequency | 30 to 83 kHz | | Vertical Frequency | 56 to 61 Hz (DisplayPort)
56 to 75 Hz (DVI)
56 to 75 Hz (VGA) | | Bit Depth / Color Support | 6-Bit+FRC (16.7 Million Colors) | | HDR Compatibility | None | | Color Gamut | 72% CIE1976 | | Response Time | 5 ms (GtG) | | Viewing Angle | Horizontal: 178°
Horizontal: 178° | | Dot Pitch | 0.270 x 0.270 mm | | | | Connectivity | 1 x VGA
1 x DVI
1 x DisplayPort
1 x 3.5 mm Input
1 x 3.5 mm Output
1 x USB Type-B (USB 2.0)
2 x USB Type-A (USB 2.0) | | HDCP Support | Yes | | Built-In Speakers | Yes, 2 x 1 W | | Supported Languages | Brazilian Portuguese
English
Finnish
French
German
Greek
Hindi
Italian
Japanese
Korean
Polish
Portuguese
Russian
Spanish
Swedish
Ukrainian | | | | Power Consumption | 28 W (Maximum)
26 W (Typical)
18.7 W (Eco)
0.3 W (Standby) | | AC Input Power | 100 to 240 VAC, 50 / 60 Hz at 2.3 A | | Power Adapter Type | Internal | | | | Certifications | CE, EPEAT GOLD, FCC, REACH, RoHS, TCO Certified, TUV, UL, cUL, as per Manufacturer | | | | Height Adjustment | 5.12" / 130 mm | | Rotation Adjustment | 90° | | Swivel Adjustment | 180° | | Tilt Adjustment | -5 to 35° | | Mounting-Hole Pattern | 100 x 100 mm, 100 x 200 mm | | Lock Slot | Yes | | Dimensions (W x H x D) | 22.0 x 15.6 x 9.4" / 55.9 x 39.6 x 23.9 cm (With Stand)
22.0 x 14.6 x 2.3" / 55.9 x 37.1 x 5.8 cm (Without Stand) | | Weight | 11.9 lb / 5.40 kg (With Stand)
10.6 lb / 4.81 kg (Without Stand) |
