User Manual for LG 27MK430H-B 27" 16:9 FreeSync IPS Monitor Click to enlarge the picture
Contents of the user manual for the LG 27MK430H-B 27" 16:9 FreeSync IPS
- Product category: Computer Monitors LG
- Brand: LG
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for LG Computer Monitors
 |
User manual for the LG 27MK430H-B 27" 16:9 FreeSync IPS contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any LG product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official LG user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a LG product will considerably shorten its lifespan!
|
Product description 10 Factors to Consider When Selecting A Monitor for Video Editing Read More The 27MK430H-B 27" 16:9 FreeSync IPS Monitor from LG is built with an In-Plane Switching panel that provides you with vivid colors and wide viewing angles. For gamers, it has a fast 5ms response time, a 75Hz refresh rate, and supports AMD FreeSync technology. Specs-wise, it has a 1920 x 1080 Full HD resolution, a 1000:1 static contrast ratio, a 250 cd/m² brightness rating, and support for 16.7 million colors. Connect this display to your system via HDMI or VGA and tilt it to your viewing preference. Otherwise, you can install an optional VESA stand, mount, or arm using the mounting holes on the back. - AMD FreeSync
- AMD FreeSync technology syncs the display's refresh rate with your graphics card's frame rate output to reduce tearing, stutter, and ghosting for a more fluid gaming experience.
- Dynamic Action Sync
- Dynamic Action Sync minimizes input lag for smoother gaming.
- Black Stabilizer
- Black Stabilizer optimizes dark scenes to improve visibility, so that you can see enemies that may be waiting for you in the dark.
- OnScreen Control
- OnScreen Control simplifies monitor adjustments by putting them on your screen. Use it to adjust volume, brightness, and picture mode presets as well as access Screen Split 2.0 and Dual Controller options.
UPC: 719192622685 In the Box LG 27MK430H-B 27" 16:9 FreeSync IPS Monitor Power Cable HDMI Cable Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the LG 27MK430H-B 27" 16:9 FreeSync IPS Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersLG 27MK430H-B Specs | | | Size | 27" | | Panel Type | IPS-Type LCD | | Touchscreen | No | | Resolution | 1920 x 1080 | | Aspect Ratio | 16:9 | | Pixels Per Inch (ppi) | 81 ppi | | Finish | Matte | | Hardness Rating | 3H | | Maximum Brightness | 250 cd/m2 | | Contrast Ratio | 1000:1 | | Refresh Rate | 75 Hz | | Adaptive Sync Technology | FreeSync | | Bit Depth / Color Support | 8-Bit (16.7 Million Colors) | | HDR Compatibility | None | | Response Time | 5 ms (GtG) | | Viewing Angle | Horizontal: 178°
Vertical: 178° | | | | Connectivity | 1 x HDMI
1 x VGA
1 x 3.5 mm | | HDCP Support | Yes, Version 1.4 | | Built-In Speakers | None | | | | Power Consumption | 28 W (Typical)
18.6 W (Eco)
0.3 W (Standby) | | AC Input Power | 100 to 240 VAC, 50 / 60 Hz at 1.3 A | | DC Input Power | 19 VDC | | | | Height Adjustment | None | | Rotation Adjustment | None | | Swivel Adjustment | None | | Tilt Adjustment | -5 to 20° | | Mounting-Hole Pattern | 100 x 100 mm | | Lock Slot | No | | Dimensions (W x H x D) | 24.6 x 18.5 x 8.0" / 624.8 x 469.9 x 203.2 mm (With Stand)
24.6 x 14.8 x 1.7" / 624.8 x 375.9 x 43.2 mm (Without Stand) | | Weight | 10.1 lb / 4.58 kg (With Stand)
9.3 lb / 4.22 kg (Without Stand) | | | | Package Weight | 12.6 lb | | Box Dimensions (LxWxH) | 27.0 x 20.0 x 20.0" |
