User Manual for LG 27MU58-B 27" 16:9 Ultra HD 4K IPS Monitor Click to enlarge the picture
Contents of the user manual for the LG 27MU58-B 27" 16:9 Ultra HD
- Product category: Computer Monitors LG
- Brand: LG
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for LG Computer Monitors
 |
User manual for the LG 27MU58-B 27" 16:9 Ultra HD contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any LG product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official LG user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a LG product will considerably shorten its lifespan!
|
Product description 10 Factors to Consider When Selecting A Monitor for Video Editing Read More rxaqtrtqreqytdbtytsdxyuewr The black 27MU58-B 27" 16:9 Ultra HD 4K IPS Monitor from LG offers a resolution of 3840 x 2160 for increased clarity with sharp texture and details. It comes with DAS mode and is factory calibrated. It features FreeSync technology, which eliminates screen tearing that can occur in videos, games, and applications caused by the difference between a graphic card's frame rate and a monitor's refresh rate. Black Stabilizer is also featured to offer better visibility in deep dark or too-light scenes and minimizes visually compromised areas on the screen during the flash bang attack. - Flicker Safe and Reader mode maximizes visual comfort by protecting your eyes from harmful blue light and reducing the flicker level to almost zero
- Screen Split divides the display into multiple sections for different tasks by resizing the windows on the screen
- Four types of PIP (Picture-in Picture) modes among 14 options
- Black equalizer and DAS mode
- PIP mode lets you work on the main screen while watching a video in a smaller window floating on the screen
- OnScreen control allows you to modify your screen configuration with a few clicks without forcing physical buttons built in monitor
- My Display presets offer customized picture mode for specific software which automatically applies to picture mode you already preset eliminating the need to select the picture mode each time
- DDC/CI, HDCP, Six Axis Control, plug-and-play, SUPER+Resolution, and Dual Controller
- Anti-glare, 3H surface treatment
- LED Color: white (On mode), white blinking (Power Save mode)
UPC: 719192609594 In the Box LG 27MU58-B 27" 16:9 Ultra HD 4K IPS Monitor Power Cable DisplayPort Cable HDMI Cable Calibration Report Software Install CD (OnScreen Control and Dual Controller) Limited 3-Year Warranty More from Manufacturer Table of Contents
|
Upload User Manual
Have you got an user manual for the LG 27MU58-B 27" 16:9 Ultra HD 4K IPS Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersLG 27MU58-B Specs | | | Size | 27" | | Panel Type | IPS-Type LCD | | Touchscreen | No | | Resolution | 3840 x 2160 | | Aspect Ratio | 16:9 | | Pixels Per Inch (ppi) | 163 ppi | | Finish | Matte | | Hardness Rating | 3H | | Maximum Brightness | 250 cd/m2 | | Contrast Ratio | 1000:1 | | Refresh Rate | 60 Hz | | Adaptive Sync Technology | FreeSync | | Horizontal Frequency | 30 to 135 kHz | | Vertical Frequency | 56 to 61 Hz
40 to 60 Hz (DisplayPort) | | Bit Depth / Color Support | 8-Bit+FRC (1.07 Billion Colors) | | HDR Compatibility | None | | Color Gamut | 72% CIE1931 | | Response Time | 5 ms (GtG) | | Viewing Angle | Horizontal: 178°
Vertical: 178° | | Dot Pitch | 0.1554 x 0.1554 mm | | | | Connectivity | 2 x HDMI 2.0
1 x DisplayPort 1.2
1 x 3.5 mm Output | | HDCP Support | Yes, Version 2.2 | | Built-In Speakers | None | | Supported Languages | Brazilian Portuguese
English
Finnish
French
German
Greek
Italian
Japanese
Korean
Polish
Portuguese
Russian
Spanish
Swedish
Traditional Chinese
Ukrainian | | | | Power Consumption | 37 W (Typical)
29.5 W (Eco)
0.5 W (Standby) | | AC Input Power | 100 to 240 VAC, 50 / 60 Hz | | Power Adapter Type | Internal | | Power Supply | 40 W | | | | Certifications | BSMI, CE, EPEAT GOLD, FCC, REACH, RoHS, TCO Certified, TUV, UL, VCCI, cUL, as per Manufacturer | | | | Height Adjustment | None | | Rotation Adjustment | None | | Swivel Adjustment | None | | Tilt Adjustment | -2 to 15° | | Mounting-Hole Pattern | 100 x 100 mm | | Lock Slot | No | | Dimensions (W x H x D) | 24.9 x 18.2 x 8.0" / 63.2 x 46.2 x 20.3 cm (With Stand)
24.9 x 14.8 x 2.4" / 63.2 x 37.6 x 6.1 cm (Without Stand) | | Weight | 12.3 lb / 5.58 kg (With Stand)
11 lb / 4.99 kg (Without Stand) | | | | Package Weight | 16.2 lb | | Box Dimensions (LxWxH) | 28.0 x 17.0 x 5.0" |
