User Manual for LG 27UD68-P 27" 16:9 4K UHD IPS Monitor Click to enlarge the picture
Contents of the user manual for the LG 27UD68-P 27" 16:9 4K UHD
- Product category: Computer Monitors LG
- Brand: LG
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for LG Computer Monitors
 |
User manual for the LG 27UD68-P 27" 16:9 4K UHD contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any LG product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official LG user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a LG product will considerably shorten its lifespan!
|
Product description 10 Factors to Consider When Selecting A Monitor for Video Editing Read More Multitask, play games, and more on the 27UD68-P 27" 16:9 4K UHD IPS Monitor from LG. With a large 27" display featuring a 3840 x 2160 UHD resolution, you have the screen space to multitask with ease, making it possible to greatly enhance workflows. For those in need of color accuracy, this LG monitor covers over 99% of the sRGB color palette, offering accurate and true to life color representations. The 10-bit (8-bit + A-FRC) display also features a 5 ms response time for reduced ghosting, a 300 cd/m² brightness rating, and 1000:1 contrast ratio for deeper dark and brighter light colors.
Setup and configuration of this display is simple as it comes equipped with HDMI 2.0 and DisplayPort 1.2 ports. Once configured, users can easily adjust various aspects of the display such as brightness, picture modes, and more using the intuitive on-screen control feature. It is even possible to split up the screen space using the Split Screen 2.0 option to divide up the screen into two or three side-by-side windows or four windows, as well as a variety of picture-in-picture configurations.
For the gamer, this monitor offers a variety of functions to enhance gameplay. With FreeSync, which is only available via DisplayPort, this monitor is able to calibrate itself with the graphics card present in the computer to reduce lag or stutter during gameplay. The 27UD68-P monitor even comes equipped with three gaming modes, FPS1/FPS2, RTS, and Custom, so you can tailor the display attributes to the type of game you're playing. For intense gaming action, LG has incorporated both Black Stabilizer and Action Sync features into this display to even out dark areas of the screen and provide a smoother, more fluid gaming experience. General Features - 4K UHD IPS Display
- With over 99% coverage of the sRGB spectrum this LG monitor is a great solution for professional photographers, graphic designers or anyone looking for highly accurate color.
- On-Screen Control
- On-Screen Control puts a host of essential monitor settings into a handy window for quick, easy access. Brightness, picture mode presets, Screen Split 2.0 and Dual Controller and more can now be adjusted with just a few clicks of the mouse, instead of hard buttons on the monitor.
- Split Screen 2.0
- Customize your monitor layout for multitasking with the latest version of LG Screen Split. Resize and display multiple windows at once, with 14 options including four different picture-in-picture (PIP) choices.
- 4K UHD Gaming
- This 4K UHD display features 8.3 million pixels on a screen with a resolution of 3840 x 2160. That's four times the resolution of Full HD for an even more immersive gaming experience.
- FreeSync
- With FreeSync, gamers can experience seamless, fluid movement throughout hi-res, fast-paced games. FreeSync eliminates tearing and stuttering that can occur because of differences between a graphic card's frame rate and a monitor's refresh rate.
- Game Modes
- Set Game Mode for optimal gaming conditions. There are 3 modes, 2 First-Person-Shooter modes and a RTS pre-set mode so you can choose the best mode for your games.
- Advanced Gaming Features
- Quickly optimize monitor settings to activate Black Stabilizer to reveal superior detail in dark scenes while the Dynamic Action Sync feature assures smooth, fluid gaming action.
- Other Features
- Picture mode
Reader mode
Original ratio
Color weakness
Picture-in-Picture
Picture-by-Picture
Flicker safe
Automatic standby
Six axis control
Smart energy saving
Super Resolution+ UPC: 719192200609 In the Box LG 27UD68-P 27" 16:9 4K UHD IPS Monitor Power Cord HDMI Cable Cable Holder Limited 1-Year Warranty User Manual PDF 6.2mb Table of Contents
|
Upload User Manual
Have you got an user manual for the LG 27UD68-P 27" 16:9 4K UHD IPS Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersLG 27UD68-P Specs | | | Size | 27" | | Screen Area | 23.53 x 13.24" / 59.77 x 33.63 cm | | Panel Type | IPS-Type LCD | | Touchscreen | No | | Resolution | 3840 x 2160 | | Aspect Ratio | 16:9 | | Pixels Per Inch (ppi) | 163 ppi | | Maximum Brightness | 300 cd/m2 | | Dynamic Contrast Ratio | 5,000,000:1 | | Refresh Rate | 60 Hz | | Adaptive Sync Technology | FreeSync | | Bit Depth / Color Support | 8-Bit+FRC (1.07 Billion Colors) | | HDR Compatibility | None | | Color Gamut | 99% sRGB | | Response Time | 5 ms (GtG) | | Viewing Angle | Horizontal: 178°
Vertical: 178° | | Dot Pitch | 0.1557 x 0.1557 mm | | | | Connectivity | 1 x DisplayPort 1.2
1 x HDMI 2.0 | | Built-In Speakers | None | | | | Power Consumption | 29 W (Typical) | | AC Input Power | 100 to 240 VAC, 50 / 60 Hz | | Power Adapter Type | Internal | | Power Supply | 40 W | | | | Certifications | ENERGY STAR, EPEAT GOLD, as per Manufacturer | | | | Dimensions (W x H x D) | 24.2 x 17.9 x 7.3" / 61.5 x 45.5 x 18.5 mm (With Stand)
24.2 x 14.4 x 1.9" / 61.5 x 36.6 x 4.8 mm (Without Stand) | | Weight | 10.8 lb / 4.9 kg (With Stand) | | | | Package Weight | 16.0 lb | | Box Dimensions (LxWxH) | 27.2 x 17.5 x 5.5" |
