User Manual for LG 32ML600M-B 31.5" 16:9 HDR IPS Monitor Click to enlarge the picture
Contents of the user manual for the LG 32ML600M-B 31.5" 16:9 HDR IPS
- Product category: Computer Monitors LG
- Brand: LG
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for LG Computer Monitors
 |
User manual for the LG 32ML600M-B 31.5" 16:9 HDR IPS contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any LG product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official LG user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a LG product will considerably shorten its lifespan!
|
Product description 10 Factors to Consider When Selecting A Monitor for Video Editing Read More Built with support for HDR 10, which will enable more shades, gradients, and nuances for its 16.7 million colors, the 32ML600M-B 31.5" 16:9 HDR IPS Monitor from LG features a native resolution of 1920 x 1080 with a 75 Hz refresh rate. It also features In-Plane Switching (IPS) technology, a 16:9 aspect ratio, an anti-glare coating with a 3H hardness rating, a typical contrast ratio of 1200:1, a typical brightness level of 300 cd/m2, and a 5 ms response time. Using the 178° horizontal and vertical viewing angles, it is possible to watch content from virtually any position. This display has two HDMI inputs, one VGA input, and a 3.5mm headphone jack.
LG has engineered the 32ML600M-B with support for 95% of the DCI-P3 (CIE1976) and 99% of the sRGB color gamuts. To further help improve viewing and accessibility, this display features a vertical tilt of -5 to 20° once mounted to the included stand base and stand body. It also features a 100mm VESA mount for wall mounting. General Features - Full HD IPS Display with True Color
- Enjoy the detail and clarity of Full HD 1080p resolution and with IPS technology, response times are shortened, and color reproduction is improved, allowing users to view the screen at virtually any angle.
- HDR 10
- HDR-compatible monitors display brighter whites and darker blacks compared to conventional displays. HDR renders dark and bright areas of an image with more details, which were not discernible under the old SDR standards.
- Color Range with 95% DCI-P3
- This LG display supports a wide color spectrum, with up to 95% of the DCI-P3 color gamut and 99% of the sRGB color gamut, which is good for image editing and accurately expressing the color of digital contents.
- Dynamic Action Sync
- Minimize input lag with Dynamic Action Sync so you can catch action in real time.
- Black Stabilizer
- Keep visibility even in dark scenes. LG's Black Stabilizer senses dark scenes and helps make it brighter so that you can find the enemies hiding and waiting to attack your player in the dark.
- Crosshairs
- Target point is fixed in the center to help enhance shooting accuracy.
- OnScreen Control
- OnScreen Control is simple and intuitive. You can customize your display options with a few simple clicks.
- Wall Mountable
- This monitor gives you the freedom to take it off the desk and hang it on the wall. Liberate your viewing options and save desktop space with this wall-mountable LG monitor.
UPC: 719192631113 In the Box LG 32ML600M-B 31.5" 16:9 HDR IPS Monitor HDMI Cable External Power Adapter Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the LG 32ML600M-B 31.5" 16:9 HDR IPS Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersLG 32ML600M-B Specs | | | Size | 31.5" | | Panel Type | IPS-Type LCD | | Touchscreen | No | | Resolution | 1920 x 1080 | | Aspect Ratio | 16:9 | | Pixels Per Inch (ppi) | 69 ppi | | Finish | Matte | | Hardness Rating | 3H | | Maximum Brightness | 300 cd/m2 | | Contrast Ratio | 1200:1 | | Refresh Rate | 75 Hz | | Adaptive Sync Technology | None | | Bit Depth / Color Support | 8-Bit (16.7 Million Colors) | | HDR Compatibility | HDR10 | | Color Gamut | 95% DCI-P3
95% CIE1976
99% sRGB | | Response Time | 5 ms | | Viewing Angle | Horizontal: 178°
Vertical: 178° | | Dot Pitch | 0.1212 x 0.3637 mm | | | | Connectivity | 2 x HDMI Input
1 x VGA Input
1 x 3.5 mm Output | | | | Power Consumption | 39 W (Maximum)
36.7 W (Typical)
0.3 W (Standby) | | AC Input Power | 100 to 240 VAC, 50 / 60 Hz | | Power Adapter Type | External | | | | Operating Temperature | 32 to 104°F / 0 to 40°C | | Storage Temperature | -4 to 140°F / -20 to 60°C | | Operating Humidity | 0 to 80% | | Storage Humidity | 0 to 85% | | | | Mounting-Hole Pattern | 100 x 100 mm | | Dimensions (W x H x D) | 28.7 x 20.2 x 8.2" / 729.4 x 513.3 x 209.3 mm (With Stand)
28.7 x 16.9 x 1.8" / 729.4 x 430.3 x 45.0 mm (Without Stand) | | Weight | 14.5 lb / 6.58 kg (With Stand)
13.6 lb / 6.17 kg (Without Stand) | | | | Package Weight | 20.3 lb | | Box Dimensions (LxWxH) | 32.0 x 20.0 x 6.0" |
