User Manual for Lilliput 339 DW 7" Wireless FPV IPS Monitor with Dual 5.8 GHz Receivers Click to enlarge the picture
Contents of the user manual for the Lilliput 339 DW 7" Wireless FPV
- Product category: FPV (First Person View) Components Lilliput
- Brand: Lilliput
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Lilliput FPV (First Person View) Components
 |
User manual for the Lilliput 339 DW 7" Wireless FPV contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Lilliput product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Lilliput user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Lilliput product will considerably shorten its lifespan!
|
Product description The Lilliput 339/DW 7" Wireless FPV Monitor, in black, is designed for aerial photography monitoring and offers up to a 1.2 mile wireless distance. It features dual 5.8 GHz receivers and is capable of wirelessly receiving a signal from each and displaying two signals in various split-screen configurations. The two receivers independently cover 4 bands and a total of 32 channels. The monitor also has a timer function that provides up to a 4-hour countdown of flight time and alerts you when there's only one minute left, helping avoid accidents.
The 329/DW features an IPS panel with a 178° viewing angle. The display has a resolution of 1200 x 800 and a brightness of 400 cd/m². A sunshade is included that will help you see clearer in sunlight. The monitor also comes with an internal 2600mAh battery that runs for approximately 3-4 hours, and also comes with a VESA mount battery bracket and both F970 and LP-E6 battery plates. The bracket secures on the back of the monitor, and the battery plates can be used interchangeably by simple snap-on attachment. Batteries are sold separately. An F970 battery provides approximately 5 hours of operation and an LP-E6 battery about 2 hours. - Additional Features
-
- 7" IPS aerial photography monitor
- Up to a 1.2 mile wireless distance
- Dual 5.8 GHz receivers -- covers 4 bands and 32 channels
- Capable of displaying two signals in split-screen configurations
- Up to 4-hour countdown timer function
- HDMI input, AV input/output
- 1200 x 800 resolution
- 178° viewing angle
- 400 cd/m² brightness
- 800:1 contrast ratio
- Built-in speaker
- Internal 2600mAh battery and corresponding battery level indicator
- VESA battery bracket and F970 and LP-E6 battery plates included
- Automatic switching between PAL/NTSC depending on location
- Sunshade included
In the Box Lilliput 339/DW 7" Wireless FPV IPS Monitor with Dual 5.8 GHz Receivers (Black) 75mm VESA Battery Bracket F970 Battery Plate LP-E6 Battery Plate 2600mAh Internal Rechargeable Battery 12 VDC Adapter Flexible Folding Sun Shade 2 x Antennas 5.8 GHz Omnidirectional Antenna HDMI Cable AV Input Cable AV Output Cable Shoe Mount FPV Bracket Type A FPV Bracket Type B Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Lilliput 339 DW 7" Wireless FPV IPS Monitor with Dual 5.8 GHz Receivers in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersLilliput 339DW-B Specs | Panel | 7" (17.8 cm) IPS | | Wireless Range | 1.2 miles / 6560 ft (2000 m) | | Resolution | 1280 x 800 | | Aspect Ratio | 16:9 | | Brightness | 400 cd/m² | | Contrast Ratio | 800:1 | | Viewing Angle | 178/178° (H/V) | | Inputs | 1 x HDMI
1 x AV | | Output | 1 x AV | | Speaker | Built-in | | Current | 1300 mA | | Input Voltage | 7-24 VDC | | Power Consumption | ≤18 W | | Operating Temperature | -4 to 140°F (-20 to 60°C) | | Storage Temperature | -22 to 158°F (-30 to 70°C) | | Dimensions | 7.2 x 5 x 1.2" (18.5 x 12.6 x 3 cm) | | Weight | 0.84 lb (385 g) | | | | Package Weight | 2.31 lb | | Box Dimensions (LxWxH) | 10.9 x 9.15 x 2.7" |
