User Manual for Lilliput 3G-SDI Quad Split Multiviewer Click to enlarge the picture
Contents of the user manual for the Lilliput 3G-SDI Quad Split Multiviewer
- Product category: Multiviewer Processors Lilliput
- Brand: Lilliput
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Lilliput Multiviewer Processors
 |
User manual for the Lilliput 3G-SDI Quad Split Multiviewer contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Lilliput product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Lilliput user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Lilliput product will considerably shorten its lifespan!
|
Product description The 3G-SDI Quad Split Multiviewer from Lilliput is a multi-function device: 3G-SDI full screen/2/3/4 Split Multiviewer with SDI & HDMI output, 3G-SDI to HDMI signal converter, two SDI distribution amplifiers with SDI & HDMI outputs, and 4x1 3G-SDI switcher with SDI & HDMI output. The SDI and HDMI output format can provide up/down scaling and frame rate conversion. All the functions can be easily set by built-in DIP switches, USB keyboard, and PC via a LAN port. - 16 Group Preset Layouts
- Includes frequently used modes like quad split, full screen, triple windows, PiP, and PoP mode.
- 11 Output Formats Selectable
- 4-channel 3G/HD/SD auto adaptive inputs, 2-channel 3G-SDI and 1-channel HDMI outputs. Four inputs can be showed simultaneously on the same display. From 720p25 to 1080p60, 11 signal output formats are supported.
- User-Defined UMD and Audio Meter Overlay
- Set 13 characters UMD overlay separately and adjust its size and position freely. The size and position of the 2-channel audio metering can also be user-defined.
- Easy Control Over DIP Switches
- Adjust the DIP switches to set the functions by finger. It also can be remote set by using a software by connecting it with a PC via LAN.
- USB port for keyboard control
- Threaded locking power connector
- Detachable bracket design for wall mounting
In the Box Lilliput 3G-SDI Quad Split Multiviewer Power Adapter Mounting Bracket Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Lilliput 3G-SDI Quad Split Multiviewer in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersLilliput MV0430 Specs | Connectors | 4 x SD/HD/3G-SDI, video input, 75 Ohms
2 x SD/HD/3G-SDI, video output, 75 Ohms
1 x HDMI Type A, video output
1 x LAN port, firmware and configuration
1 x USB port, keyboard | | Control | 1 x 12-position DIP Switch, format configuration
1 x 4-position DIP Switch, display configuration | | SDI Input Formats | 1080p 60/59.94/50/30/29.97/25/24/23.98
1080PsF 30/29.97/25/24/23.98
1080i 60/59.94/50
720p 60/59.94/50/30/29.97/25/24/23.98
625i 50 PAL
525i 59.94 NTSC | | SDI, HDMI Video Output Formats | 1080p 60/50/30/25/24
1080i 60/50
720p 60/50/30/25 | | SDI Video Rates | SD/HD/3G-SDI | | SDI Compliance | SMPTE 292M / SMPTE 259M / SMPTE 424M | | Color Space | SDI & HDMI: YUV or RGB for inputs. YUV for outputs | | SDI Auto Switching | Auto selects SD, HD, and 3G-SDI on input | | Power Consumption | 4.5 W | | Voltage | 12 VDC | | Operating Temperature | -4 to 140°F / -20 to 60°C | | Storage Temperature | -22 to 158°F / -30 to 70°C | | Humidity | 0 to 90% non-condensing | | Dimensions | 4.9 x 4.1 x 1.0" / 12.6 x 10.4 x 2.5 cm | | Weight | 1 lb / 465 g | | | | Package Weight | 2.8 lb | | Box Dimensions (LxWxH) | 6.8 x 6.8 x 3.7" |
