Product description The Link Electronics 812-OP/H is an analog pulse generator designed to provide composite sync, composite blanking, and color subcarrier for studio and/or system applications. It receives Genlock from an 812-OP/C or 812-OP/D mounted in the same SPG-812 chassis, then this module places the timing pulses down the motherboard bus as reference. - Timing Pulses
- The 812-OP/H pulse generator uses timing pulses to lock the PLL on the module and reset the vertical and horizontal counters within the complex programmable logic devices. This action times up all counters by an external reference.
- Subcarrier Output
- The subcarrier output is filtered for low harmonic distortion and is driven by a discrete amplifier.
- Rack Card
- This device is a rack card that operates within the SPG-812 frame.
In the Box Link Electronics 812-OP/H Analog Pulse Generator - Color Subcarrier, Composite Sync, Composite Blanking, BNC, Rack Card 10 Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Link Electronics 812-OP H Analog Pulse Generator - Color Subcarrier, Composite Sync, Composite Blanking, BNC, Rack Card in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersLink Electronics 812-OP/H Specs | Output | Composite Sync, 4 Vpp @ 75 ohms, on a BNC connector
Composite Blanking, 4 Vpp @ 75 ohms, on a BNC connector
Color Subcarrier, 2 Vpp @ 75 ohms, on a BNC connector | | Television System | NTSC @ 3.58 MHz | | Control | External Reference Input
Horizontal Phasing
Vertical Phasing
Sub-Carrier Phasing | | Power Source | Power derived from Rack Frame | | Dimensions (WxDxH) | 1 x 10 x 4.27"
2.5 x 25.4 x 10.8cm | | Weight | 0.5 lbs
227 grams | | | | Package Weight | 2.0 lb | | Box Dimensions (LxWxH) | 14.0 x 11.0 x 6.0" |
