Product description The Link Electronics LEI-550 is a 1x6 SDI video distribution amplifier; this unit offers automatic EQ and gain control in a compact size. - Gain Control
- Gain control outputs allows the user to adjust video levels to correct parameters.
- Compact Size
- The compact size of the LEI-550 allows the user to mount three units in a one rack unit space.
- Equalization
- The signal is reshaped with automatic equalization also reslicing and DC restoring.
In the Box Link Electronics LEI-550 1x6 SDI Distribution Amplifier - Composite Video, Gain Control, Desktop 10 Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Link Electronics LEI-550 1x6 SDI Distribution Amplifier - Composite Video, Gain Control, Desktop in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersLink Electronics LEI-550 Specs | Input | SDI Video, 143 Mb/s to 360 Mb/s @ 75 ohms, on a BNC connector | | Output | SDI Video x6, 143 Mb/s to 360 Mb/s @ 75 ohms, on BNC connectors | | Video Bandwidth | Accepts up to 360 Mb/s | | Video Signal-to-Noise Ratio | Not Specified by Manufacturer | | Differential Phase | Not Specified by Manufacturer | | Differential Gain | Not Specified by Manufacturer | | Video Control | On and Off Button
A and B Gain control | | Coupling | DC Servo AC | | Dimensions (WxDxH) | 5.5 x 9.25 x 1.0"
13.97 x 23.5 x 2.5cm | | Weight | 2 lbs
8 oz | | Power Source | 120 to 240 VAC @ 50/60 Hz | | | | Package Weight | 2.0 lb | | Box Dimensions (LxWxH) | 14.0 x 11.0 x 6.0" |
