User Manual for Link Electronics PSR-824 Remote Control Panel for LINK 800 VSW Series Video and Audio Switchers Click to enlarge the picture
Contents of the user manual for the Link Electronics PSR-824 Remote Control Panel
- Product category: Router, Switcher & Patchbay Accessories Link Electronics
- Brand: Link Electronics
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Link Electronics Router, Switcher & Patchbay Accessories
|
User manual for the Link Electronics PSR-824 Remote Control Panel contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Link Electronics product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Link Electronics user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Link Electronics product will considerably shorten its lifespan!
|
Product description The PSR-824 Remote Control Panel for LINK 800 VSW Series Video and Audio Switchers from Link Electronics is a panel that allows you to remotely control and monitor LINK 800 VSW Series Video and Audio Switchers. It is an 8x1 controller that features an RS-232 serial port to allow interface with a computer. Communications with the switcher is handled via an RS-485 compatible serial link and an RJ-11 modular jack.
The combination of this panel with the switcher allows for communication distances of up to 1,000'. Active video and audio channels are indicated by a pair of seven-segment displays. This unit is mounted in a 1U chassis and features a reduced depth to accommodate placement on a table or desktop.
Depending on the switcher model, (16) or (8) video inputs and (2) outputs are available using true 75 Ohm BNC connectors. If desired, customers may also order 800 Series switchers with the internal video signal bus divided in half, effectively giving them two independent 8x1 switchers in one box. - Remote Control
- This panel allows you to remotely control and monitor LINK 800 VSW Series Video and Audio Switchers.
- 1,000' Communication Distance
- The combination of this panel with the switcher allows for communication distances of up to 1,000'.
- Desktop or Rackmount
- This unit is mounted in a 1U chassis and features a reduced depth to accommodate placement on a table or desktop.
In the Box Link Electronics PSR-824 Remote Control Panel for LINK 800 VSW Series Video and Audio Switchers Remote Control Panel Ten-Year Limited Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Link Electronics PSR-824 Remote Control Panel for LINK 800 VSW Series Video and Audio Switchers in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersLink Electronics PSR-824 Specs | Inputs | RS-232: 9 Pin D Connector, Female, Computer Control
RS-485: Two, In and Out, RJ-11, Remote Control | | Controls | 8 input selections, momentary | | Operating Conditions | Temperature: 0° to 50°C ambient
Humidity:0% to 90% non-condensing | | Power | Input: 120/240 VAC, 50/60Hz
Power:3 Watts | | Dimensions | 1-3/4 x 19 x 4-1/2" | | Weight | 2.5 lbs |
