Product description

The 6x4 HD-SDI Matrix Switcher from Lumantek is an all-in-one matrix switcher that supports live switching of media or cameras with 6 x SD/HD-SDI inputs and 4 x SD/HD-SDI outputs. The switcher first output A has two BNC connector ports, and an additional BNC port 7 provides Fill/Key input with selected license option.
It features frame sync on each input, on-board control panel, and supports remote control via an optional console controller. The switcher is equipped with 10-bit processing and analog audio embedding with 2 x stereo XLR inputs. All video/audio channels are controlled separately. One HDMI preview channel allows the display of six video source inputs with two other background channels.
  • Hybrid between video matrix and switcher
  • Simultaneous multi-channel switching supported
  • Supported resolutions: 1080i 60/59.94/50, 720p 60/59.94/50, 625i, 525i
  • Supported HDMI output resolutions: 1080p 60/50, 720p 60/50
  • Auxiliary output supported for the Presenter view
  • Supported Preview mode: HDMI 1080p, 720p, 576p, 480p
  • Optional fill and key system
  • Black console included (connected through Ethernet cable)
In the Box Lumantek 6x4 HD-SDI Matrix Switcher
  • Limited 1-Year Warranty
  • Table of Contents




    Upload User Manual

    Have you got an user manual for the Lumantek 6x4 HD-SDI Matrix Switcher in electronic form? Please send it to us and help us expand our library of instruction manuals. Thank you, too, on behalf of other users.

    To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
    Upload PDF user manual Upload DOC user manual
    Please enter here the link to the user manual of this product:





    OR

    Enter here the file with the user manual of this product from your computer/phone:
    (60MB max; Permitted formats: PDF)

    0%


    Technical parameters

    Lumantek EZ-PRO VM6 Specs

    Video Input 6 x BNC 75 Ohms, SD/HD-SDI
    1 x BNC 75 Ohms, Fill/Key (port 7)
    Audio Input 2 x XLR, stereo
    Video Output 4 x BNC 75 Ohms, HD-SDI
    1 x BNC 75 Ohms, HD-SDI (port A)
    Multiview Outputs 1 x HDMI, (1080p at 60/50, 720p at 60/50, 576p at 50, 487p at 60)
    Control Buttons At Front:
    6 x input select
    4 x output select
    LCD At Front:
    Status and control
    LED Indicator Large 'L' logo LED at front to identify device status
    USB Rear: Easy to use GUI application (Firmware update)
    Internal Processing 4:2:2 10-bit
    Resolution Supported 1920 x 1080i at 59.94/60/50
    1280 x 720p at 59.94/60/50
    720 x 576i at 50
    720 x 487i at 59.94
    Power Input 115 to 240 VAC at 50/60 Hz
    Power Consumption 30 W maximum
    Operation Temperature 32 to 104°F / 0 to 40°C
    Dimensions 1.7 x 19 x 9.4" / 44 x 483 x 240 mm
    Weight 6.8 lb / 3.1 kg
