Product description

• 2 x Mackie SRM450 - 1000W 12" Portable Powered Loudspeaker The Mackie SRM450 is a powered loudspeaker that features a 12" high-output woofer and a 1.4" titanium dome compression driver. With 1000 watts of power, you get the high output you need in a package that is designed to be tough, lightweight and portable.

  Featuring one-button speaker mode selection for scenario-specific voicing (PA, DJ, Monitor and Soloist), the speaker allows you to customize your sound to best fit your application. Complete with an integrated, gain adjustable 2-channel mixer that features two XLR/TRS Combo inputs and a stereo RCA input, the SRM450 can handle anything from mics to guitars to MP3 players and more.
  Features:
  • • 12" high-output woofer
    • 1.4" titanium dome compression driver
    • Eliminate feedback with one-button automatic "Feedback Destroyer"
    • Precision 2-way crossover
    • Driver time alignment & phase correction
    • System protection / limiting
    • Monitor-specific angle and voicing mode perfect for cutting through on stage
    • Flyable for permanent install, both vertically and horizontally
    • Durable, portable design
    • Weight: 37.0 lb (16.8 kg)
  UPC: 663961044225
• 2 x Auray SS-4420 Steel Speaker Stand The SS-4420 Steel Speaker Stand from Auray is built for durability and it can support speakers weighing up to 100 pounds. It features a telescoping center column with five height adjustments ranging from 46" to 76". It also features collapsible legs for portability, as well as non-slip feet for traction on surfaces such as dance floors and stages.
  • Center column fits 1-3/8" speaker mounts and 1-1/2" adapter is included
  • Locking pin fits into any of five predrilled holes to secure desired height setting
  • Center brace connects tripod legs for increased stability
  UPC: 847628015852
• 2 x Kopul Premium Performance 3000 Series XLR M to XLR F Microphone Cable - 20' (6.1 m), Black The black Kopul Premium Performance 3000 Series XLR M to XLR F Microphone Cable (20') is designed to be an extremely quiet and flexible cable that is ideal for the most demanding live sound and performance applications. The cable is engineered to be durable and to provide protection against EMI, RFI, and static noise. While the cable's color-coding affords the ability to quickly differentiate between multiple connections on stage, it provides a pleasant aesthetic quality at the same time.

  Premium Performance 3000 Series cables are made from 24-AWG OFC copper wire that's wrapped with PE insulation and a conductive PVC inner shield. A cotton-yarn inner layer helps reduce electrostatic and microphonic noise. 95% dual-spiral shielding makes the cable resistant to EMI and RFI noise. The Neutrik XX silver connectors provide a high level of connectivity, and all the solder connections are shrink-wrapped for protection.
  • 95% dual-spiral shielding offers protection from EMI and RFI noise
  • Twin conductive PVC inner shielding provides 100% coverage of the core conductor. It helps keep the cable's signal from radiating and affecting nearby cables, and also helps prevent external EMI from penetrating to the cable's core
  • 24-AWG oxygen-free stranded copper inner core provides the best possible conductivity
  • Cotton yarn reduces electrostatic and microphonic noise
  • All solder points shrink-wrapped for protection
  • Neutrik XX silver connectors offer high conductivity
  • Caged type contact and improved ground contact
  UPC: 847628558304
• Mackie 802VLZ4 8-Channel Ultra-Compact Mixer The Mackie 802VLZ4 8-Channel Ultra-Compact Mixer features Onyx microphone preamps in a desk-friendly, ultra-compact design, suitable for professional applications with a lower input need. From every input to every output, the mixer is designed to provide the highest headroom and lowest noise possible for maximum signal integrity.

  The mixer is built-like-a-tank with a rugged solid-steel chassis and high-contrast controls for tactile control. With features like instrument level inputs, phantom power, and level metering, the 802VLZ4 offers a true step-up performance and durability that is suitable for your professional applications.
  • 8-Channel mixer featuring high-headroom, low-noise design
  • 3 Boutique-Quality Onyx Microphone Preamps:
    Wide 60 dB gain range
    128.5 dB dynamic range
    +22 dBu line input handling
    Extended frequency response
    Distortion under 0.0007% (20 Hz to 50 kHz)
  • Improved RF rejection, suitable for broadcast applications
  • Phantom power for condenser microphones
  • Eight high-headroom line inputs
  • Selectable instrument inputs on first 2 channels; no DI box needed
  • 3-Band EQ (80 Hz, 2.5 and 12 kHz)
  • 18 dB/octave 100 Hz low-cut filter on microphone input channels
  • AUX send, level, pan, and PFL solo on each channel
  • Stereo return for connecting FX processor or other stereo source
  • ALT 3/4 stereo bus for added routing flexibility
  • Control room / phones source matrix
  • High-resolution 12-segment stereo meters
  • Sealed rotary controls resist dust and grime
  • Built-like-a-tank rugged steel chassis with powder-coat finish
  • High-visibility, high-contrast controls deliver convenient at-a-glance visual feedback
  • Universal power supply for worldwide use
  • Applications: Live sound mixing, houses of worship, clubs, gymnasiums, banquet halls, conference rooms, boardrooms, studio and field recording, multimedia applications, broadcast, and many more
  UPC: 663961039832
• Polsen HDM-16-S Handheld Dynamic Performance Microphone The HDM-16-S Handheld Dynamic Performance Microphone from Polsen is a reliable and rugged handheld microphone with an integrated on/off switch. The supercardioid polar pattern and frequency response is optimized for the human voice and can be used for live stage, vocal presentation, and studio applications. The microphone's polar pattern is designed to eliminate off-axis sound. Additionally, an on/off switch lets you quickly silence the mic when necessary. Built with rugged construction, the Polsen HDM-16-S will withstand the rigors of transport and live performances. A 16.4' XLR cable, carry pouch, and a mic clip are also included.
  Optimized for Vocals
  • The HDM-16-S microphone is optimized for live vocal performances. It has a wide frequency response with impressive sensitivity, which makes this microphone capable of capturing singers and presenters with clarity and accuracy.
  Supercardioid Polar Pattern
  • The dynamic supercardioid microphone capsule minimizes background noise, making the HDM-16-S ideal for vocals or speech, whether onstage or in the studio.
  On/Off Switch
  • Don't let your audience hear what you don't want them to hear. The on/off switch is a convenient feature that lets you quickly mute the microphone between songs or during a pause in your presentation.
  Rugged and Portable
  • Take your microphone anywhere. The heavy-duty metal construction will withstand the rigors of transport and onstage use. With the included 16-foot XLR cable, you can plug into any mixing board, sound system, or amplifier with an XLR input jack.
  UPC: 847628598447
• 2 x Mackie SRM450B Canvas Speaker Bag The Mackie SRM450 Bag is a canvas speaker bag made to carry the Mackie SRM450 speaker from one gig to another. It is made from 1500 denier nylon with reinforced corners and heavy duty zippers. The bag is carried by a sturdy shoulder strap.
  • 1500 denier Nylon speaker bag with reinforced corners
  • Outside cable pouch
  • Heavy duty zippers
  • Padded shoulder strap
  Compatible with;
  • • Mackie SRM450 Two Way Active Loudspeaker
  UPC: 889406825796
• Pioneer DJ HDJ-1500 Professional DJ Headphones (Silver) The silver Pioneer HDJ-1500 Professional DJ Headphones deliver the precision audio quality and durability professional DJs depend on. The HDJ-1500's feature 50mm drivers with rare-earth magnets for high output levels. To keep DJs monitoring accurately in their noisy line of work, the HDJ-1500 headphones feature enhanced isolation from outside sounds.

  HDJ-1500 headphones are built for comfort and longevity with magnesium alloy joints at the earcups, allowing for swivel, rotation, and dependable single-ear monitoring. The cable itself is detachable and easily replaced in the rare event of a short or break. The headphones include a carrying pouch and a 1/4" adapter.
  Superb Sound Quality
  • Accurate sonic reproduction across the frequency spectrum, achieved with 50mm drivers, aluminum wire voice coils, and rare earth magnets
  Rugged Design
  • Magnesium alloy construction provides tough yet lightweight hanger and hinges
  Comfortable Earpads
  • Leatherlike polyurethane earpads are kind to ears during prolonged usage, while narrow earcups create excellent isolation from outside sound.
  UPC: 884938156691

• 2 x SRM450 - 1000W 12" Portable Powered Loudspeaker suqfrrzwec
• Limited 3-Year Warranty for Electronics
• Limited 2-Year for Drivers

• 2 x Auray - SS-4420 Steel Speaker Stand

• 2 x Kopul - Premium Performance 3000 Series XLR M to XLR F Microphone Cable - 20' (6.1 m), Black

• 802VLZ4 8-Channel Ultra-Compact Mixer

• Polsen - HDM-16-S Handheld Dynamic Performance Microphone

• 2 x SRM450B Canvas Speaker Bag - for Mackie SRM450 Two Way Active Loudspeaker (Black)

• Pioneer DJ - HDJ-1500 Professional DJ Headphones (Silver)

Upload User Manual

Please enter here the link to the user manual of this product: OR Enter here the file with the user manual of this product from your computer/phone: (60MB max; Permitted formats: PDF) 0%

Technical parameters

• 2 x Mackie SRM450 - 1000W 12" Portable Powered Loudspeaker

  Configuration	Active
  Total Power Capacity	500 W RMS 1000 W Peak
  Amplifier Power Rating	LF: 400 W RMS 800 W Peak HF: 100 W RMS 200 W Peak
  Amplifier Class	LF: Class-D HF: Class-AB

  HF Driver	1 x 1.4" / 36 mm Titanium Tweeter
  LF Driver	1 x 12" / 304.8 mm Woofer
  Magnet	HF: Ferrite LF: Ferrite

  Frequency Response	47 Hz to 20 kHz -3 dB 42 Hz to 23 kHz -10 dB
  Maximum SPL	128 dB SPL
  Coverage Angle	90° H x 45° V
  I/O Impedance	Input: 8 kOhms (Balanced) 10 MOhms (Unbalanced) 25 kOhms (Unbalanced)
  THD	<1%
  Protections	Power Supply, RMS, Thermal

  Audio I/O	2 x Combo XLR / 1/4" TRS Line/Mic Input 1 x Stereo RCA Input 1 x XLR Male Balanced Thru Passive when the Ch 1 / Mix switch is in the "out" (Ch 1) position. Active when the Ch 1 / Mix switch is in the "in" (Mix) position

  Crossover	3 kHz
  Dynamic Processing	Peak Limiter

  AC Input Power	100 to 120 VAC, 50 / 60 Hz 220 to 240 VAC, 50 / 60 Hz
  AC Power Connector	1 x IEC
  Power Consumption	160 W

  Mounting	1 x Pole Socket 3 x M10
  Cooling	Convection
  Construction Material	Metal Grille, Polypropylene
  Operating Temperature	32 to 104°F / 0 to 40°C
  Dimensions	26.1 x 16.0 x 14.8" / 663.0 x 406.0 x 376.0 mm
  Weight	37 lb / 16.8 kg

  Box Dimensions (LxWxH)	27.5 x 16.5 x 15.0"

• 2 x Auray SS-4420 Steel Speaker Stand

  Type	Speaker Stand
  Load Capacity	100 lb / 45.4 kg
  Mount Size	1-3/8" 1-1/2"
  Height Adjustment Range	46 to 76" / 118 to 194 cm
  Material of Construction	Steel
  Weight	8 lb / 3.6 kg

  Box Dimensions (LxWxH)	39.5 x 5.3 x 5.0"

• 2 x Kopul Premium Performance 3000 Series XLR M to XLR F Microphone Cable - 20' (6.1 m), Black

  Connector 1	3-Pin XLR Male
  Connector 2	3-Pin XLR Female
  Cable Length	20' / 6.1 m
  Shielding	95% Spiral
  Wire Gauge	24 AWG
  Contact Plating	Silver

  Box Dimensions (LxWxH)	8.6 x 7.0 x 0.4"

• Mackie 802VLZ4 8-Channel Ultra-Compact Mixer

  Noise	Main Mix Noise: Main Mix Knob Down, Channel Level Knobs Down: XLR: -95 dBu TRS: -101 dBu Main Mix Knob at Unity, Channel Level Knobs Down: XLR: -90 dBu TRS: -96 dBu Main Mix Knob at Unity, Channel Level Knobs at Unity: XLR: -84 dBu TRS: -90 dBu (20 Hz to 20 kHz bandwidth, channels 1 to 3 gain at unity, channel EQs flat, all channels assigned to main mix, channel 1 panned left, 2 panned right, 3 to 8 centered)
  Total Harmonic Distortion (THD)	Microphone Pre at Insert: <0.001% (1 kHz @ 35 dB gain, 20 Hz to 20 kHz bandwidth)
  Crosstalk / Attenuation	Main Mix Knob Down: -75 dBu Channel Alt / Mute Switch Engaged: -100 dBu Channel Level Knob Down: -100 dBu (1 kHz relative to 0 dBu, 20 Hz to 20 kHz bandwidth, line in, 1/4" main out, gain at unity)
  Frequency Response	Microphone Input to Main Output (Gain at Unity): +0, -1 dB, 20 Hz to 50 kHz +0, -3 dB, <10 hz to>100 kHz
  Equivalent Input Noise	150 Ohms; Termination: -128.5 dBu, 20 Hz to 20 kHz Microphone input to insert send out, maximum gain
  Common Mode Rejection Ratio	Better than -70 dB at 1 kHz
  Maximum Level	Microphone In: +21 dBu Tape In: +22 dBu All Other Inputs: +22 dBu Main Mix XLR Out: +28 dBu All Other Outputs: +22 dBu
  Impedance	Microphone In: 2.55 kOhms Channel Insert Return: 5 kOhms All Other Inputs: 17 kOhms or greater Tape Out: 1 kOhm Phones Out: 60 Ohms All Other Outputs: 120 Ohms
  Equalizer	High Shelving: ±15 dB at 12 kHz Mid Peaking ±15 dB at 2.5 kHz Low Shelving: ±15 dB at 80 Hz
  Power Consumption	13 W, 100 to 120 VAC, 50 to 60 Hz
  Power Supply	External (AC Connector): 2-Pin IEC 250 VAC
  Operating Temperature	32 to 104°F (0 to 40°C)
  Dimensions (H x W x D)	10.7 x 8.9 x 1.8" (273.0 x 227.0 x 47.0 mm)
  Weight	5.5 lb (2.5 kg) with power supply 4.5 lb (2.0 kg) without power supply

  Box Dimensions (LxWxH)	15.8 x 12.2 x 4.3"

• Polsen HDM-16-S Handheld Dynamic Performance Microphone

  Transducer	Dynamic
  Polar Pattern	Supercardioid
  Frequency Response	50 Hz to 16 kHz
  Impedance	600 Ohms ±30% at 1 kHz
  Sensitivity	-54 dB ±3 dB (0 dB= 1 V/Pa @ 1 kHz)
  Output Connector	3-pin XLR
  Cable Length	16.4' (5 m)
  Dimensions (L x Diam)	7 x 2.1" (17.8 x 5.3 cm)
  Weight	0.7 lb (317.5 g)

  Box Dimensions (LxWxH)	8.7 x 4.9 x 2.7"

• 2 x Mackie SRM450B Canvas Speaker Bag

  Type	Bag
  Interior Dimensions	15.4 x 26 x 14.8" / 39 x 66 x 37.6 cm
  Carrying/Transport Options	Shoulder Strap
  Type of Closure	Zipper
  Material of Construction	Nylon
  Pocket Size	21 x 7 x 1.5" / 53.3 x 17.8 x 3.8 cm
  Exterior Dimensions (W x H x D)	14 x 29 x 18" / 35.6 x 73.7 x 45.7 cm

  Box Dimensions (LxWxH)	27.0 x 17.0 x 3.0"

• Pioneer DJ HDJ-1500 Professional DJ Headphones (Silver)

  Driver Size	2" / 50 mm
  Driver Type	Dynamic
  Earcup Style	Closed-Back

  Frequency Response	5 Hz to 30 kHz
  Impedance	32 Ohms
  Maximum Sound Pressure Level (SPL)	108 dB
  Maximum Power Handling	3500 mW

  Audio Connector	1/8" (3.5 mm)
  Connector Plating	Gold

  Cable Length	4 to 10' / 1.2 to 3 m (Coiled)

  Weight	10.1 oz / 285 g

  Box Dimensions (LxWxH)	9.4 x 9.2 x 3.1"
