Product description

The Mackie 402VLZ4 4-Channel Ultra-Compact Mixer features Onyx microphone preamps in an ultra-compact design and is suitable for professional low-input applications. From every input to every output, the mixer is designed to provide the highest headroom and lowest noise possible for maximum signal integrity.

The mixer is built like a tank with a rugged solid-steel chassis and high-contrast controls for discernible tactile control. With features like instrument level inputs, phantom power, and level metering, the 402VLZ4 4-Channel Ultra-Compact Mixer is a good choice for anybody who is big on performance, but light on inputs. The bottom panel of the mixer features has three non-threaded holes that allow it to be fitted with an optional microphone stand adapter (sold separately). This lets you support the mixer on a standard microphone stand and adjust its height and level to whatever suits your preferences.
  • 4-Channel mixer featuring high-headroom, low-noise design
  • 2 Boutique-Quality Onyx Microphone Preamps:
    Wide 60 dB gain range
    128.5 dB dynamic range
    +22 dBu line input handling
    Extended frequency response
    Distortion under 0.0007% (20 Hz to 50 kHz)
  • Improved RF rejection, suitable for broadcast applications
  • Phantom power for condenser microphones
  • 4 high-headroom line inputs
  • Selectable instrument inputs on first 2 channels; no DI box needed
  • 2-band EQ (80 Hz and 12 kHz)
  • 18 dB/octave 100 Hz low-cut filter on microphone input channels
  • High-resolution 8-segment stereo meters
  • Sealed rotary controls resist dust and grime
  • Built-like-a-tank rugged steel chassis with powder-coat finish
  • High-visibility, high-contrast controls deliver convenient at-a-glance visual feedback
  • Universal power supply for worldwide use
  • Applications: Live sound mixing, houses of worship, clubs, gymnasiums, banquet halls, conference rooms, boardrooms, studio and field recording, multimedia applications, broadcast, and many more
In the Box Mackie 402VLZ4 4-Channel Ultra-Compact Mixer
  • Power Supply
  • Limited 1-Year Warranty
  • Table of Contents




    Upload User Manual

    Have you got an user manual for the Mackie 402VLZ4 4-Channel Ultra-Compact Mixer in electronic form? Please send it to us and help us expand our library of instruction manuals. Thank you, too, on behalf of other users.

    To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
    Upload PDF user manual Upload DOC user manual
    Please enter here the link to the user manual of this product:





    OR

    Enter here the file with the user manual of this product from your computer/phone:
    (60MB max; Permitted formats: PDF)

    0%


    Technical parameters

    Noise Main Mix Noise:
    Main Mix Knob Down, Channel Level Knobs Down: -103 dBu
    Main Mix Knob at Unity, Channel Level Knobs Down: -98 dBu
    Main Mix Knob at Unity, Channel Level Knobs at Unity: -92 dBu
    Signal-to-Noise Ratio, ref. +4 dBu 102 dB
    (20 Hz to 20 kHz bandwidth, 1/4" main out, channels 1-2 gain at unity, channel EQs flat, stereo-pan button in)
    Total Harmonic Distortion (THD) 20 Hz to 80 kHz Bandwidth: <0.005%
    20 Hz to 20 kHz Bandwidth: <0.003%
    (1 kHz @ 35 dB gain)
    Crosstalk / Attenuation Main Mix Knob Down: -70 dBu
    Channel Level Knob Down: -94 dBu
    (1 kHz relative to +10 dBu, 20 Hz to 20 kHz bandwidth, microphone in, 1/4" main out, gain at unity)
    Frequency Response Microphone Input to Main Output (Gain at Unity):
    +0, -1 dB, 20 Hz to 50 kHz
    +0, -3 dB, <10 hz to>100 kHz
    Equivalent Input Noise 150 Ohms; Termination: -128.5 dBu, 20 Hz to 20 kHz
    Microphone Input to Main Output, Maximum Gain
    Common Mode Rejection Ratio Better than -70 dB at 1 kHz
    Maximum Level Microphone In: +21 dBu
    Tape In: +24 dBu
    All Other Inputs: +22 dBu
    All Other Outputs: +22 dBu
    Impedance Microphone In: 2.55 kOhms
    Instrument Input: 1 MOhms
    All Other Inputs: 10 kOhms or greater
    Tape Out: 1 kOhm
    Phones Out: 60 Ohms
    All Other Outputs: 120 Ohms
    Equalizer High Shelving: ±15 dB at 12 kHz
    Low Shelving: ±15 dB at 80 Hz
    Power Consumption 8 W, 100 to 120 VAC, 50 to 60 Hz
    Power Supply External AC Connector: 2-Pin IEC 250 VAC
    Operating Temperature 32 to 104°F (0 to 40°C)
    Dimensions 7.3 x 5.8 x 1.6" (186.0 x 147.0 x 41.0 mm)
    Weight 3.0 lb (1.4 kg) with power supply
    2.5 lb (1.1 kg) without power supply
    Package Weight 3.35 lb
