User Manual for Manfrotto MT055CXPRO4 Carbon Fiber Tripod with 391RC2 Junior 3-Way Pan Tilt Head Click to enlarge the picture
Contents of the user manual for the Manfrotto MT055CXPRO4 Carbon Fiber Tripod with
- Product category: Tripods with Heads Manfrotto
- Brand: Manfrotto
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Manfrotto Tripods with Heads
|
User manual for the Manfrotto MT055CXPRO4 Carbon Fiber Tripod with contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Manfrotto product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Manfrotto user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Manfrotto product will considerably shorten its lifespan!
|
Product description Time-Lapse Tips and Tools Read More xxratzca This versatile tripod kit from Photo pairs the Manfrotto MT055CXPRO4 Carbon Fiber Tripod with the 391RC2 Junior 3-Way Pan/Tilt Head. This kit provides a stable camera support with a load capacity of 11 lb. It extends from 3.1 to 70.8" and weighs 6.1 lb. The 90° center column has a one finger operation, and includes an Easy Link 3/8"-16 attachment for attaching accessories such as an LED light or a reflector via a compatible arm. The mounting plate has a bull's eye bubble level that rotates 360° so you can locate it where you can see it.
The included 391RC2 Junior 3-way pan/tilt head is designed for shooting both stills and videos. It has a long locking pan handle for easy adjustment with smooth pan and tilt movements. Three separate locks control each of the pan and tilt motions. The pan handle is padded with soft non-slip rubber, and quick-release plate is included for speedy attaching and detaching of your camera. - Manfrotto MT055CXPRO4 Carbon Fiber Tripod The Manfrotto MT055CXPRO4 Carbon Fiber Tripod is a 4-section support that replaces the 055CXPRO4 tripod. It has a load capacity of 19.8 lb and extends from 3.5" to 66.9". Its carbon fiber legs are secured by the Quick Power Locks. These updated flip locks increase the tripod's rigidity by 50% compared to its predecessor.
A redesigned center column has a "one finger" operation, and includes an Easy Link 3/8"-16 attachment for attaching accessories such as an LED light or a reflector via a compatible arm. The center column can be positioned horizontally, allowing for low-angle and macro photography. The upper disc where a tripod head is mounted has been redesigned as well, and now has a bull's eye bubble level that rotates 360° so you can locate it where you can see it. This allows you to level your camera on both the horizontal and vertical planes. UPC: 719821364658 - Manfrotto 391RC2 3-Way, Pan-and-Tilt Head with 200PL-14 Quick Release Plate The 391RC2 3-Way, Pan-and-Tilt Head from Manfrotto has a load capacity of 11 lb and can be attached to tripods or other support systems that feature a 3/8"-16 mount. It includes an integrated RC2 quick release cam lock and a 200PL-14 Quick Release Plate. RC2 compatible quick release plates such as the 200PL-14 can be removed from the head by pulling the cam lock's spring-loaded lever, which also allows the plate to be quickly reattached.
Cameras, sport optics, or camcorders that are compatible with a 1/4"-20 mount can be connected to the quick release plate before securing it to the pan-and-tilt head. The head can be rotated 360°, and tilted 90° backwards or forwards, as well as sideways for portrait orientation. Each of these three movements function independently of each other and can be locked into place. - 391RC2 3-Way, Pan-and-Tilt Head
-
- 11 lb load capacity
- Compatible with tripods or support systems that feature a 3/8"-16 mount
- Can be rotated 360°, and tilted 90° backwards or forwards, as well as sideways for portrait orientation
- Rotation, backwards and forwards tilt, as well as portrait orientation tilt each function independently of each other and can be locked into place
- Integrated, RC2 quick release cam lock
- Durable, aluminum-alloy construction
- 200PL-14 Quick Release Plate
-
- Compatible with Manfrotto RC2 quick release cam lock
- Measures 1.7 x 2.1 x 0.4" and has a rubberized, non-slip surface
- 1/4"-20 mount
- Removable, anti-twist index pin
- Durable, aluminum-alloy construction
UPC: 719821297666 In the Box - MT055CXPRO4 Carbon Fiber Tripod xxratzca
- Limited 6-Month Warranty, Extendable to 10 Years with Product Registration
- 391RC2 3-Way, Pan-and-Tilt Head with 200PL-14 Quick Release Plate
Table of Contents
|
Upload User Manual
Have you got an user manual for the Manfrotto MT055CXPRO4 Carbon Fiber Tripod with 391RC2 Junior 3-Way Pan Tilt Head in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parameters - Manfrotto MT055CXPRO4 Carbon Fiber Tripod
| | | Load Capacity | 19.8 lb / 9 kg | | Maximum Working Height | 66.9" / 169.9 cm | | Max Height without Center Column | 55.1" / 140 cm | | Minimum Working Height | 3.5" / 8.9 cm | | Folded Length | 21.3" / 54.1 cm | | Head Mount Type | 3/8"-16 Screw | | Weight | 4.6 lb / 2.1 kg | | Materials | Carbon Fiber | | Bubble Level | Yes | | | | Leg Lock Type | Flip Lock | | Independent Leg Spread | Yes | | Leg Sections | 4 | | | | Center Column Sections | 1 | | Center Column Extension Type | Rapid | | Lateral / 90-Degree Center Column | Yes | | | | Box Dimensions (LxWxH) | 21.6 x 5.5 x 5.5" | - Manfrotto 391RC2 3-Way, Pan-and-Tilt Head with 200PL-14 Quick Release Plate
| | | Head Type | Pan & Tilt Head | | Base Mount | 3/8"-16 Thread | | Camera Mounting Screw | 1/4"-20 Male | | Quick Release Plate Type | 200PL-14 | | Load Capacity | 11.0 lb / 4.99 kg | | Number of Bubble Level(s) | None | | Material | Aluminum | | | | Lateral Tilt | -90
