User Manual for Marshall Electronics CV506-H12 Miniature High-Speed Camera Click to enlarge the picture
Contents of the user manual for the Marshall Electronics CV506-H12 Miniature High-Speed Camera
- Product category: Industrial & Multi-Purpose Cameras Marshall Electronics
- Brand: Marshall Electronics
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Marshall Electronics Industrial & Multi-Purpose Cameras
 |
User manual for the Marshall Electronics CV506-H12 Miniature High-Speed Camera contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Marshall Electronics product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Marshall Electronics user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Marshall Electronics product will considerably shorten its lifespan!
|
Product description Use the CV506-H12 Miniature High-Speed Camera from Marshall to capture broadcast, sports, racing, or any high-speed action and create slow-motion, high-resolution video. This tiny camera features a 2MP 1/2.8" Sony Exmor sensor and records up to 1080p60 and up to 120 fps slow-motion video.
The CV506-H12 can be controlled with a joystick or by an RS-485 Visca-capable controller, which are both connected via the included breakout cable. Mic and line connectors are also provided on the breakout cable, providing TRS stereo output. An HDMI 2.0 port on the back of the unit outputs HD video for recording and broadcast. Configurable camera settings include paint, white balance, exposure, gain, pedestal (black), gamma, shutter, and others.
The camera includes a 3.6mm M12 prime lens with a 72° horizontal angle of view, and since the M12 lens mount is interchangeable you can replace the stock lens with one of the supported lenses listed below. A 12V power adapter is also included. - Compatible Lenses
- Prime Lenses:
CV-4702.3-3MP: 2.3mm, f2.2 3MP M12 lens; Horiz. AOV = 126°
CV-4702.8-3MP-IR: 2.8mm, f2.6 3MP M12 lens; Horiz. AOV = 100°
CV-4703.6-3MP: 3.6mm, f2.0 3MP M12 lens (included); Horiz. AOV = 72°
CV-4706-3MP-IR: 6mm, f2.4 3MP M12 lens; Horiz. AOV = 48°
CV-4708.0-3MP: 8mm, f1.8 3MP M12 lens; Horiz. AOV = 40°
CV-4712.0-3MP: 12mm, f1.8 3MP M12 lens; Horiz. AOV = 33°
CV-4716.0-2MP: 16.0mm, f1.8 2MP M12 lens; Horiz AOV = 25°
Varifocal Lenses:
CV-2812-3MP: 2.8–12mm, f1.4 3MP Varifocal M12 lens; Horiz. AOV = 108–3°
CV-0622-5MP: 6–22mm, f1.6 5MP Varifocal M12 lens; Horiz. AOV = 46–16° UPC: 801813191073 In the Box Marshall Electronics CV506-H12 Miniature High-Speed Camera 3.6mm M12 Mount Lens 12V Power Adapter I/O Breakout Cable Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Marshall Electronics CV506-H12 Miniature High-Speed Camera in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersMarshall Electronics CV506-H12 Specs | Sensor | 2 MP 1/2.8" Sony Exmor | | Color Sampling | 4:2:2 | | Lens Mount | M12 | | Input | 1 x Visca (mic, line, RS-485) | | Output | 1 x HDMI | | Supported Resolutions & Formats | 1080p: 120/100/60/59.94/50/30/29.97/25/24
720p: 120/100/60/59.94/50/30/29.97/25/24
1920 x 1080i: 60/59.94/50 | | Power | 12 V | | Mounting Thread | 1 x 1/4"-20 | | Dimensions | 2.2 x 1.9 x 1.6" / 5.5 x 4.7 x 4 cm | | Weight | 4 oz / 113 g | | | | Package Weight | 1.195 lb | | Box Dimensions (LxWxH) | 9.4 x 5.0 x 2.7" |
