User Manual for Marshall Electronics V-1055BNC 1 3-Inch CCD Black and White Video Camera in Housing with C CS- Lens Mount, Ultra Low-Light Sensitivity Click to enlarge the picture
Contents of the user manual for the Marshall Electronics V-1055BNC 1 3-Inch CCD
- Product category: Industrial & Multi-Purpose Cameras Marshall Electronics
- Brand: Marshall Electronics
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Marshall Electronics Industrial & Multi-Purpose Cameras
|
User manual for the Marshall Electronics V-1055BNC 1 3-Inch CCD contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Marshall Electronics product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Marshall Electronics user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Marshall Electronics product will considerably shorten its lifespan!
|
Product description The V-1055BNC is among the smallest self-contained video camera devices with a housing and lens mount. Only 1.5 inches square and 1 inch deep, the camera is an excellent choice for machine-vision, robotics and computer imaging applications. Along with industrial uses the camera is easily used for convert surveillance purposes. C- or CS-mount lens and V-PS12 power supply are both sold separately. - C- and CS-Mount Lenses
- The V-1055BNC does not come with a lens but it does have a C/CS-mount adapter right on its minuscule housing. A wide range of small lenses with the appropriate mount are available from wide-angle pinhole lenses to longer, narrower field of view lenses. The camera can also be attached to other imaging devices like microscopes.
- Low Light Capable
- Outputting an impressive 420 lines from its BNC connector, the V-1055BNC has a very sensitive CCD that captures good quality black and white video down to 0.05 lux with a signal to noise ratio of at least 48 dB.
- Automatic Iris Function
- The electronic iris built into the circuit-board automatically adjusts from dim to bright lighting conditions. And because the camera's CCD is an advanced design (Sony's HAD technology is used), the images tend to be very stable with low smear levels with bright spot imagery and detailed high-contrast conditions.
UPC: 801813030488 In the Box Marshall Electronics V-1055BNC 1/3-Inch CCD Black and White Video Camera in Housing with C/CS- Lens Mount, Ultra Low-Light Sensitivity 1 Year Parts and Labor Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Marshall Electronics V-1055BNC 1 3-Inch CCD Black and White Video Camera in Housing with C CS- Lens Mount, Ultra Low-Light Sensitivity in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersMarshall Electronics V-1055-BNC Specs | Application | Security, Machine Vision, Scientific | | Signal System | NTSC | | Image Sensor | 1/3-Inch CCD | | Lens Mount | C-Mount and CS-Mount | | Number of Pixels | 250,000 Pixels | | Horizontal Resolution | 420 TV Lines | | Minimum Illumination | 0.05 Lux | | Signal-to-Noise Ratio | Greater Than 48 dB | | Signal Connectors | Composite Video- BNC (x 1)
Power- Coaxial (x 1) | | Power Requirements | 12-Volts DC | | Power Consumption | 100 mA | | Operating Temperature | -4° to 122° F
-20° to 55° C | | Dimensions (WxHxD) | 1.5 x 1.5 x 1.0 inches
38.1 x 38.1 x 25.4 mm | | Weight | 3 oz.
85.05 g | | | | Package Weight | 1.0 lb | | Box Dimensions (LxWxH) | 3.0 x 3.0 x 2.0" |
