Product description The Martin Professional Rush PAR 2 CT Zoom is a bright single-lens LED PAR Can with fully premixed white color temperatures, well suited for key lighting applications within the cabaret clubs, theaters, conferences, and exhibition environments where color temperature control of white light is critical.
Rush PAR 2 CT Zoom features 12 x 10W CW/WW (cool white / warm white) LEDs with a color temperature from 2700 to 7800K, which allows the fixture to be matched for multiple sources from tungsten to metal halide. Its motorized zoom offers a 10 to 60° Additionally, the fixture offers electronic dimming and shutter effects including strobe, pulse, instant open, and blackout.
For control options, the PAR 2 CT Zoom features a single, standalone scene that's programmable from the rear control panel with LED display, as well as seven channels of DMX. The Martin Professional Rush PAR 2 CT Zoom ships with a power cord, a gel holder, and a mounting bracket. -
- Single-lens bright LED PAR Can
- 12 x 10W warm white / cool white (WW/CW) LEDs
- Pre-mixed white light ranging from 2700 to 7800K
- 10 to 60° motorized zoom
In the Box Martin Professional Lighting Rush PAR 2 CT Zoom - LED PAR Can - Professional Moving Head (WW/CW) Power Cord Mounting Bracket Gel Holder Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Martin Professional Lighting Rush PAR 2 CT Zoom - LED PAR Can - Professional Moving Head in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersMartin Professional Lighting RUSH Par 2 CT Zo... Specs | Dynamic Effects | Color Temperature: 2700 to 7800K
Color Mixing: WW/CW (warm white & cold white)
Electronic Dimming: 16-bit, 0 to 100%, four dimming curve options
Strobe and Pulse Effects: Variable speed and action, random strobe
Electronic Shutter Effect: Instant open and blackout
Zoom: Motorized, 10 to 60° | | Control and Programming | Control Options: DMX, single standalone scene
DMX Channels: 7
DMX Address Setting: Control panel with LED display
Standalone Programming: Control panel with LED display
Protocol: USITT DMX512/1990 | | Optics | Light Source: 12 x 10 W CW/WW LEDs
Minimum LED Lifetime: 50,000 hours (to >70% luminous output)
CRI (Color Rendering Index): 90 | | Construction | Color: Black
Housing: Aluminum
Protection Rating: IP20 | | Installation | Mounting: Adjustable bracket, surface or truss mount
Location: Dry location
Orientation: Any
Minimum Distance to Illuminated Surfaces: 8.0" / 203.2 mm
Minimum Distance to Combustible Materials: 4.0" / 101.6 mm | | Connectors | AC Power Input: Neutrik PowerCon
AC Power Throughput: Neutrik PowerCon
DMX Data In/Out: 5-pin locking XLR | | Thermal | Cooling: Forced air (temperature-regulated, low noise)
Maximum Ambient Temperature (Ta Max.): 104°F / 40°C
Minimum Ambient Temperature (Ta Min.): 32°F / 0°C
Total Heat Dissipation: 520 BTU/hour (±10% at full intensity) | | Approvals | EU Safety: EN 60598-2-17 (EN 60598-1), EN 62471, EN 62493
EU EMC: EN 55015, EN 55103-1, EN 55103-2, EN 61000-3-2, EN 61000-3-3, EN 61547
US Safety: UL 1573
US EMC: 47 CFR Part 15 Class A
Canadian Safety: CSA C22.2 No. 166
Canadian EMC: ICES-003 Class A
Australia/NZ: C-TICK N4241 | | Electrical | AC Power: 100 to 240 V nominal, 50/60 Hz
Power Supply Unit: Auto-ranging electronic switch mode
Fuse: T 6.3 A
Typical Power and Current:
120 V, 60 Hz: 1.25 A, 151 W, PF 0.993
230 V, 50 Hz: 0.66 A, 148 W, PF 0.961 | | Dimensions (L x W x H) | 10.5 x 11.3 x 13.0" / 266.7 x 287.0 x 330.2 mm | | Weight | 12.1 lb / 5.5 kg |
