User Manual for Meade 10x42 RidgeWay Binocular Click to enlarge the picture
Contents of the user manual for the Meade 10x42 RidgeWay Binocular
- Product category: Binoculars Meade
- Brand: Meade
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Meade Binoculars
 |
User manual for the Meade 10x42 RidgeWay Binocular contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Meade product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Meade user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Meade product will considerably shorten its lifespan!
|
Product description The B&H Binocular Buying Guide Read More Sporting a magnification and objective lens size favored by hunters, birders, and avid outdoor enthusiasts around the world, the Meade 10x42 RidgeWay Binocular performs even when observing in challenging light conditions. Outfitted with BAK4 roof prisms and anti-reflection fully coated lens surfaces, the binocular delivers bright and sharp high-contrast images with true-to-life color and crisp clarity. The 42mm objectives gather generous amounts of light to further boost performance in less-than-ideal conditions without the bulk and weight of larger objectives.Designed to withstand the rigors of the trail, the optical tubes are nitrogen filled and O-ring sealed to make them waterproof and resistant to internal fogging when moving through extreme temperature variations. The chassis is made of a combination of aluminum and plastic and wrapped in a protective rubber armor that provides a slip-resistant grip in the rain. To further cut weight while providing users with more area to grip, Meade employs an open-bridge configuration with a dual hinge. Protecting the objectives and eyepieces are tethered caps that come off fast for easy reaction to glassing opportunities without the possibility of losing them. - Optical Performance
-
- High 10x power enables detailed observation and identification at long range
- 42mm objectives boost low-light performance without adding excessive bulk and weight
- Compact roof prism design maintains a slim form factor without sacrificing performance
- BAK4 prisms glass delivers a round exit pupil and a crisp and clear image with limited edge distortion
- Anti-reflection fully coated lenses improve light transmission for bright and clear images with accurate color rendition
- 294-foot field of view at 1000 yards
- Use and Handling
-
- Open-bridge/dual-hinge configuration reduces weight without sacrificing strength or stability
- Large slip-resistant center focusing wheel is easy to manipulate in cold or wet conditions or when wearing gloves
- Right-eye dioptric adjustment allows for precise focusing for sharper and clearer views
- 57-73mm interpupillary adjustment range allows easy use by a wide variety of users
- Twist-up click-stop rubber eyecups for comfortable use with or without eyewear
- 15mm eye relief reduces eyestrain for easier viewing
- 4.2mm exit pupil will cover most pupils as they open in low light to keep the entire scene in view at all times
- Construction Details
-
- Bridge design provides more surface area for hands to improve grip security
- Chassis made of both aluminum and plastic to reduce weight without sacrificing strength or stability
- Nitrogen filled and O-ring sealed to be waterproof and resistant to internal fogging when moving through extreme changes in temperature and environmental conditions
- Exterior rubber armor protects against bumps and impacts while offering slip-resistance to the grip
- Tethered objective caps and one-piece ocular rainguard provide optimum protection against rain and dust while remaining close at hand without the possibility of losing them
- Weight: 20 ounces
UPC: 709942997828 In the Box Meade 10x42 RidgeWay Binocular Lens Cloth Carry Case Neck Strap 1-Piece Ocular Rainguard 2 x Tethered Objective Lens Caps Limited Lifetime Warranty Summer Binocular Buying Guide Christopher Witt 07/14/2016 A Guide to Marine Binoculars Todd Vorenkamp 06/25/2015 Pentax Sport Optics Binocular Roundup Joseph Albanese 06/24/2015 ueszrzbxtrewyvurdasuzz A Guide to Birding with Binoculars Todd Vorenkamp 06/16/2015 Table of Contents
|
Upload User Manual
Have you got an user manual for the Meade 10x42 RidgeWay Binocular in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersMeade RidgeWay Specs | Prism Type | Roof | | Magnification | 10x | | Objective Lens Diameter | 42 mm | | Angle of View | 5.6° (Actual) | | Field of View | 294.0' @ 1000 yd / 97.61 m @ 1000 m | | Minimum Focus Distance | 20.5' / 6.2 m | | Exit Pupil Diameter | 4.2 mm | | Eye Relief | 15.0 mm | | Interpupillary Adjustment | 57 to 73 mm / 2.2 to 2.9" | | Focus Type | Center | | Tripod Mount | None | | Dimensions | Length: 6.3" / 16.0 cm | | Weight | 20.3 oz / 576 g | | | | Package Weight | 1.8 lb | | Box Dimensions (LxWxH) | 7.0 x 6.0 x 2.8" |
