User Manual for Metric Halo ULN-2 2d - FireWire Digital Audio Interface Click to enlarge the picture
Contents of the user manual for the Metric Halo ULN-2 2d - FireWire
- Product category: Audio Interfaces & Systems Metric Halo
- Brand: Metric Halo
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Metric Halo Audio Interfaces & Systems
|
User manual for the Metric Halo ULN-2 2d - FireWire contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Metric Halo product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Metric Halo user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Metric Halo product will considerably shorten its lifespan!
|
Product description The ULN-2 2d from Metric Halo is a portable, high quality FireWire based, multi-format audio converter and interface. Housed in a single space rack-mount chassis, the unit provides 12 inputs and 14 outputs of simultaneous I/O, while having the ability to be powered entirely from the FireWire bus of a laptop computer, or from an appropriate DC power source. The ULN-2 2d is equipped with 2 balanced analog inputs on Neutrik combo connectors, 2 channels of digital I/O (AES/EBU and S/PDIF) and 8 channels of ADAT lightpipe I/O. Two balanced analog outputs and 2 balanced monitor outputs are available for connecting directly to power amps or self powered monitors. Wordclock I/O and dual FireWire connectors, along with 24-bit, 96kHz converters on all channels, make the ULN-2 2d a perfect tool for digital recording. The unit is the perfect tool for capturing audio wherever inspiration hits, in the studio or on the road. Well suited to any recording situation, the microphone preamps provide exceptional detail and an ultra-fast slew rate. Fully balanced analog inserts allow outboard analog dynamics processing to be introduced between the preamps and the A/D converters. On-board DSP powers the v.5 MIO Console that can function as a mixer, router and control application. The software can be used to route any input to any output, providing powerful and flexible mixing possibilities. A "Record Panel" allows for straight forward recording of incoming audio without the need for additional DAW software. This is particularly useful in situations where immediate editing is not required, but stable, fool-proof recording is. Hardware - Fully portable FireWire audio interface and format converter
- Bus powered or use with external adapter that provides sufficient power for other peripherals
- 12 simultaneous input channels and 14 simultaneous output channels, all with full 24-bit/96kHz resolution 1
Please Note: Totals include using 2-channels analog, 2 channels AES or S/PDIF, and 8-channels ADAT I/O close - 2 independent channels of high gain (up to +72dB), low-noise microphone-preamplification with switchable +48V phantom power
- Selectable stereo AES/EBU or S/PDIF digital inputs and outputs
- Up to 8-channels of ADAT Lightpipe input and output
- Wordclock I/O on BNC connectors
- Sample rate conversion (SRC) on AES or S/PDIF digital I/O
- Headphone amplifier with front panel volume knob
- Balanced stereo master control room monitor output with front panel volume control
- 10 front-panel preset system/routing memories for stand-alone operation
- 4-pin XLR power port for compatibility with most location battery systems
- Front panel metering for analog inputs and outputs
- OS X drivers with multi-interface support
MIO Software Console - v.5 Configurable mixer for near-zero latency mixing and routing
- Completely customizable mixing engine can be created from scratch or with any of the templates included - with the v.5 Mixer, the ULN-2 can be a mastering console in the morning, a tracking console in the afternoon, and a live sound mixer/recorder in the evening
- Record Panel provides no-frills, but very stable recoding feature for all inputs
- A single input can be multi-ed and given various levels of DSP processing and then recorded as separate tracks
- An arbitrary number of busses can be created (limited only by the capabilities of the hardware), each of which can be used as a master bus (routed to an output) or an auxiliary bus (routed to other busses), with bus able to be dynamically adjustable from mono to 7.1 surround
- Integrated surround monitor controller/switcher
- "Character" slot available on all channels provides analog modeling of various circuit types, including tube based electronics, etc.
- Full console metering of every channel and mix bus
- Total recall of every console parameter
UPC: 832081000026 In the Box Metric Halo ULN-2 2d - FireWire Digital Audio Interface Universal External Power Supply Power Cable 0.5m IEEE 1394 6-Pin FireWire Cable 4.5m IEEE 1394 6-Pin FireWire Cable MIO Software CD-ROM Rack Ears with Fasteners One (1) Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Metric Halo ULN-2 2d - FireWire Digital Audio Interface in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersMetric Halo ULN-2 2d Specs | Converters | 24-bit | | Sample Rates | 44.1, 48, 88.2 and 96kHz | | Analog Input | 2 x Neutrik Combo
2 x 1/4" TRS phone FX Return | | Analog Output | 4 x 1/4" TRS phone
2 x 1/4" TRS phone FX Send | | Digital Input | 1 x XLR AES/EBU
1 x RCA coaxial S/PDIF
1 x TOSlink ADAT lightpipe | | Digital Output | 1 x XLR AES/EBU
1 x RCA coaxial S/PDIF
1 x TOSlink ADAT lightpipe | | MIDI In/Out | No | | Sync In/Out | 2 x BNC Wordclock I/O | | Headphone Output | 1 x 1/4" TRS phone | | THD + N | 0.0005% @ 1kHz (+9dBu in @ 6dB gain) | | Dynamic Range | A/D: 110dB
D/A: 120dB | | Frequency Response | 8Hz to 50kHz, +/-1.0dB | | Power Requirements | FireWire bus
1 x 4-pin XLR 9 to 30V DC (pin-4 hot) 15W
1 x 2.1 coaxial 9 to 30V DC, center post positive (+) | | System Requirements | PowerPC or Intel Mac
OS X 10.3.9 or better
512MB RAM
Monitor with 1024 x 768 resolution or better
ASIO 2 compatible host (Cubase, Nuendo, Logic Audio, Digital Performer, Deck or Peak)
Application that supports ASIO direct monitoring for direct monitoring-based fold-back and overdubbing | | Dimensions (WxDxH) | 13.5 x 8.25 x 1.73" (343 x 210 x 44mm) | | Weight | 4 lbs (1.8 kg) | | Specialties | Sample rate conversion (SRC) on digital I/O | | | | Package Weight | 7.7 lb | | Box Dimensions (LxWxH) | 19.5 x 14.5 x 5.0" |
