Product description The Microsemi PD-6500G 24-Port 200W Midspan provides up to 15.4W of power over Ethernet to IP telephones, wireless LAN access points, security network cameras, and many other types of data terminals over standard Ethernet data cables, leaving the network infrastructure completely unaltered. Plug-and-Play operation allows you to quickly and easily implement the midspan in an existing Ethernet infrastructure. - Safe and reliable power over existing Ethernet infrastructure
- Powerview Pro remote, web-based SNMPv3 power management environment
- Cisco and legacy PoE support
- Plug-and-play installation
UPC: 844117001280 In the Box Microsemi PD-6500G 24-Port 200W Midspan Limited Lifetime Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Microsemi PD-6500G 24-Port 200W Midspan in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersMicrosemi PD-6524G/AC/M Specs | Number of Ports | 24 | | Data Rates | Pass Through: 10/100/1000 Mb/s | | Power Over Ethernet | Pin Assignment and Polarity: 4/5 (+), 7/8 (-) | | Output Voltage | 52 VDC | | Output Power | User Port Power: 15.4 W
Aggregate Power: 200 W | | Input Power | AC Input Voltage: 90 to 240 VAC | | Input Requirements | AC Input Current: 4 A @ 110 VAC; 2 A @ 220 VAC
AC Frequency: 47 to 63 Hz | | Management | PowerView Pro included | | Indicators | System Indicator: AC Power (Green)
User Indicator: Channel Power (Green) | | Connectors | Shielded RJ-45, EIA 568A and 568B | | Ambient Operating Temperature | 32 to 104°F (0 to 40°C) | | Storage Temperature | -4 to 158°F (-20 to 70°C) | | Operating Humidity | 10 to 90%, non-condensing | | Storage Humidity | 5 to 95%, non-condensing | | Operating Altitude | -1000 to 10000' (-305 to 3048 m) | | Reliability | MTBF: 100,000 hrs. @ 77°F (25°C) | | Thermal Rating | 170/320 BTU/hour @ 240 VAC | | Regulatory Compliance | IEEE 802.3af, RoHS Compliant, WEEE Compliant, CE | | Electromagnetic Safety | FCC Part 15, Class B, EN 55022 Class B (Emissions), EN 55024 (Immunity), VCCI | | Safety Approvals | UL/cUL Per IEC60950-1
GS Mark Per IEC60950-1 | | Dimensions | 17.3 x 10.8 x 1.7" (43.8 x 27.2 x 4.4 cm) or 1 U | | Weight | 8.8 lb (4.0 kg) |
